Vishay Shielded Surface Mount Inductor Metal Composite Core 560 nH ±20% 61 A Idc IHLP6767GZERR56M11
Specifications
| Country of Origin | Israel |
|---|---|
| Brand | Vishay |
| Height | 7mm |
| Length | 17.15mm |
| Model | IHLP6767GZERR56M11 |
| Depth | 17.15mm |
| Packaging | Reel |
| Series | IHLP |
| Maximum Operating Temperature | 125°C |
| Minimum Operating Temperature | -55°C |
| Core Material | Metal Composite |
| Inductance | 560nH |
| Standards/Approvals | RoHS |
| Package/Case | 6767 |
| Maximum DC Current | 61A |
| Maximum DC Resistance | 910μΩ |
| Inductance Tolerance | ±20 % |
| Termination Style | Surface Mount |
| Maximum Self Resonant Frequency | 40MHz |
| Inductor Construction | Shielded |
Key Features
- Constructed with a metal composite core for reduced losses and durability.
- Inductor features magnetically shielded wire wound design to minimize electromagnetic interference.
- Suitable for high current and low profile power applications up to 750 kHz frequency range.
- Operates reliably within temperature ranges from -55°C to 125°C.
- Exhibits low DC resistance of 910 μΩ for enhanced efficiency.
- Compliant with RoHS standards ensuring environmental safety.
- Packaged in a 6767 reel surface mount case for ease of PCB assembly.
- Designed for applications in POL converters, DC/DC converters, battery-powered devices, and computing equipment.
Product Description
Vishay IHLP6767GZERR56M11 Shielded Surface Mount Inductor is engineered with a high-current, low-profile magnetically shielded wire wound design featuring a metal composite core. It provides 560 nH inductance with ±20% tolerance and can handle a maximum DC current of 61 A without saturation. The inductor offers ultra-low buzz noise and operates efficiently across a wide temperature range from -55°C to 125°C.
This surface mount inductor comes in a 6767 package size with dimensions of 17.15 mm length, 7 mm height, and 17.15 mm depth, specifically designed for compact electronic circuits. The maximum DC resistance is only 910 μΩ, enabling low power dissipation and high efficiency in power supply circuits.
Compliant with RoHS environmental standards, this inductor supports high transient current spikes common in POL converters, DC/DC converters, and battery-powered devices. Its shielded construction minimizes electromagnetic interference, making it ideal for sensitive applications in PDA, notebook, desktop, server devices, and FPGA power supplies.
Operating frequency can reach up to 750 kHz with a self-resonant frequency of 40 MHz, providing robust performance across various industrial and commercial electronics. The product is of new condition and manufactured in Israel, confirming quality and reliability consistent with Vishay’s standards.
Constructed with a metal composite core for durability and efficiency. Magnetically shielded wire wound choke design reduces EMI interference. Low profile surface mount packaging suitable for automated PCB assembly. Supports high currents up to 61 A maintaining low saturation levels.
Wide operating temperature range from -55°C to 125°C ensures stability. Maintains low DC resistance of 910 μΩ for efficient power delivery. RoHS compliant for environmental safety and regulatory standards. Applications include POL converters, DC/DC converters, FPGA power supplies, and battery-powered devices.
Explore the range of Vishay surface mount inductors on EnvMart for reliable and efficient electronic component solutions.
Explore more products in our Electronic Components, Power & Connectors category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has an inductance value of 560 nH with a tolerance of ±20%.
It can handle a maximum DC current of 61 A without saturation.
The dimensions are 17.15 mm in length, 17.15 mm in depth, and 7 mm in height.
It operates reliably within a temperature range from -55°C to 125°C.
The maximum DC resistance is 910 μΩ, which enhances its efficiency.
It is constructed with a metal composite core, which reduces losses and enhances durability.
The maximum self-resonant frequency is 40 MHz.
It is packaged in a 6767 reel surface mount case for ease of PCB assembly.
The inductor features a magnetically shielded wire wound design to minimize electromagnetic interference.
Yes, it is compliant with RoHS standards, ensuring environmental safety.
This model is manufactured in Israel.
