Crydom CN Series Solid State Relay 2 A Load, 280 V ac, PCB Mount, 12 V dc Control CN240A05
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 15mm |
| Length | 28mm |
| Model | CN240A05 |
| IP Rating | IP67 |
| Width | 5mm |
| Mount Type | PCB |
| Output type | MOSFET |
| Series | CN |
| Maximum Operating Temperature | 80°C |
| Contact Configuration | SPST |
| Package Type | Mini SIP-4 |
| Capacitance | 1.5pF |
| Minimum Operating Temperature | -20°C |
| Terminal type | Through Hole |
| Switching Function | Zero Cross Switching |
| Maximum Load Current | 2A |
| Standards/Approvals | UL, RoHS, CE, cUL |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 720-3950Brand: CrydomManufacturers Part No.: CN240A05 |
| Maximum Load Voltage | 280V ac |
| Minimum Load Voltage | 24V ac |
| Minimum Control Voltage | 3V dc |
| Maximum Control Voltage | 12V dc |
| Off State Leakage Current | 4mA |
Key Features
- Compact dimensions of 28mm length, 5mm width, and 15mm height allow efficient space utilization.
- Maximum load current rating of 2A supports moderate current applications.
- Operates with a control voltage range from 3V dc to 12V dc.
- Features zero cross switching for reduced electrical noise and transient suppression.
- Constructed with a plastic body providing electrical insulation and durability.
- High protection rating of IP67 ensures dust tightness and water immersion protection.
- Wide operating temperature range from -20°C to 80°C facilitates use in harsh environments.
- Through-hole terminal type for reliable PCB mounting and connections.
Product Description
Crydom CN240A05 Solid State Relay is designed for efficient and reliable switching in industrial and automation applications. This device supports a maximum load current of 2 A and can handle load voltages up to 280 V ac, making it suitable for power distribution and control circuits on PCB mounts.
The relay operates on a control voltage range of 3V dc to 12V dc, employing zero cross switching to minimize electrical noise and extend device longevity. Its compact Mini SIP-4 package measures 28mm by 5mm by 15mm to fit spaces where real estate is limited.
The plastic body construction imparts excellent insulation and resistance to wear, while the IP67 rating certifies robustness against dust and temporary water immersion, allowing deployment in demanding environmental conditions. Designed for through-hole PCB mounting with a SPST contact configuration, this relay provides a reliable electrical interface.
Additional features include a low off-state leakage current of 4mA to reduce energy waste and a MOSFET output stage for fast switching performance. The operating temperature span from -20°C to 80°C makes it versatile for diverse industrial settings like automated assembly lines and power control systems.
Package contents: 1 Pc Crydom CN240A05 Solid State Relay. Installation is straightforward either by inserting into a compatible relay socket or by soldering directly onto the PCB. Compact dimensions of 28 (L) x 5 (W) x 15mm (H) optimize space usage.
Maximum continuous load current of 2A for moderate power applications. Operating load voltage range from 24V ac minimum to 280V ac maximum. Control voltage range from 3V dc up to 12V dc for flexible activation. High ingress protection rating IP67 for resistance to dust and water ingress.
Zero cross switching reduces electrical noise and protects circuits. Plastic insulated body ensures electrical safety and longevity. Through-hole terminal type for secure PCB mounting. Low off-state leakage current (4mA) minimizes power loss in standby.
Output using MOSFET technology for high switching speed and reliability.
Ideal for industrial, manufacturing, automation, and power distribution applications requiring reliable, fast switching with high durability. Explore more Crydom Solid State Relays and related products on EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current rating of this solid state relay is 2A, making it suitable for moderate current applications.
This model operates with a control voltage range from 3V dc to 12V dc, allowing for flexible activation.
The relay can handle a maximum load voltage of 280V ac, which supports various power distribution and control applications.
It features a through-hole terminal type for reliable PCB mounting and connections.
The relay has a high ingress protection rating of IP67, ensuring it is dust-tight and protected against temporary water immersion.
The compact dimensions of this unit are 28mm in length, 5mm in width, and 15mm in height, optimizing space utilization.
The operating temperature range for this model is from -20°C to 80°C, making it suitable for harsh environments.
It employs zero cross switching technology, which minimizes electrical noise and enhances circuit protection.
The off-state leakage current is 4mA, which helps to minimize power loss in standby mode.
This relay features an SPST contact configuration, providing a reliable electrical interface for switching applications.
The output type of this model is MOSFET, which allows for fast switching performance and reliability.
This relay complies with UL, RoHS, CE, and cUL standards, ensuring it meets various safety and environmental regulations.
