TE Connectivity MTA-156 Series Straight Through Hole Pin Header, 5 Contacts, 3.96 mm Pitch, 1 Row, Unshrouded 3-641208-5

TE Connectivity 3-641208-5 MTA-156 Series Straight Through Hole Pin Header is a high-quality electronic component engineered for efficient wire-to-board connection systems. It features a 5-contact configuration with a 3.96 mm pitch and single-row layout, optimized for mass termination assembly applications.

The header’s polyester housing provides durable insulation, while the contacts are made of copper alloy plated with gold, enhancing electrical conductivity and resistance against corrosion. The pins have a 3.18 mm tail length designed for reliable through-hole soldering on printed circuit boards.

Capable of handling currents up to 7A and voltages up to 600V, this pin header operates across a wide temperature range from -65°C to 105°C, making it suitable for use in demanding industrial environments.

The unshrouded, straight-through hole design supports easy insertion and connection with complementary IDC connectors in the MTA-156 3.96 mm interconnect system. The friction lock mechanism and end-to-end stackability ensure a secure and cost-effective mating solution in wire-to-board and wire-to-wire applications.

Common applications include automotive body and chassis systems, driver information systems, safety and security electronics, as well as computer and consumer electronic devices such as desktops, notebooks, servers, storage, and workstations.

This header supports a current rating of 7A for efficient electrical performance. Constructed with a polyester housing to ensure robust insulation. Features gold-plated copper alloy contacts for excellent conductivity and corrosion resistance.

The 3.18 mm tail pin length facilitates secure through-hole soldering onto PCBs. Operates within a temperature range of -65°C to 105°C, suitable for various environments. Unshrouded design allows easy mating with compatible connectors.

Uses a friction lock mechanism and is end-to-end stackable for mass termination applications. Designed for wire-to-board mounting with straight orientation for versatile installation. Ideal for automotive, computer, and consumer electronics applications requiring secure, cost-effective connections.
