STMicroelectronics Operational Amplifier, 1.3 MHz Gain Bandwidth, 14-Pin SOIC, 3-6 V LMV324IDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | LMV324IDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | LMV321 |
| Output Current | 46mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 714-7421PBrand: STMicroelectronicsManufacturers Part No.: LMV324IDT |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 95 nA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.45V/μs |
| Input Offset Current | 25 nA |
| Low supply current | 145 μA |
| Gain bandwidth product | 1 MHz |
| Electrostatic Discharge (ESD) tolerance | 2 kV |
Key Features
- The device operates on a supply voltage range of 3 to 6 volts.
- It features a 14-pin SOIC surface-mount package suitable for compact PCB designs.
- Gain bandwidth product is 1.3 MHz for stable amplification across frequencies.
- Low input bias current of 95 nA ensures minimal signal distortion.
- The maximum operating temperature is 125°C, allowing use in harsh environments.
- Electrostatic discharge tolerance is 2 kV, enhancing device robustness.
- It supports rail-to-rail input and output for improved signal range.
- Low supply current of 145 μA makes it ideal for battery-powered devices.
Product Description
STMicroelectronics LMV324IDT is a quad-channel low power operational amplifier with a gain bandwidth product of 1.3 MHz, provided in a 14-pin SOIC surface-mount package. Designed for low voltage applications, it operates from 3 V to 6 V, making it highly efficient for battery-powered and portable equipment.
This device features rail-to-rail input and output stages, ensuring maximum signal range for precision analog signal processing. Its low input bias and offset currents and low supply current of 145 μA reduce power consumption and enhance signal integrity. The amplifier's slew rate of 0.45 V/μs and output current of 46 mA make it suitable for a variety of general purpose amplification tasks.
The LMV324IDT supports an operating temperature range of -40°C to 125°C, making it reliable for automotive applications meeting the AEC-Q100 standard, as well as demanding industrial environments. Electrostatic discharge tolerance up to 2 kV improves circuit durability.
Package dimensions are approximately 8.75 mm length, 4 mm width, and 1.65 mm height, providing a compact footprint for space-optimized PCB layouts. Low supply voltage operation from 3 to 6 V for flexible power designs. Four channels in one IC, reducing board space and cost.
RoHS compliant, meeting environmental standards. Suitable for analog signal amplification, filtering, and conditioning circuits. Ideal for use in consumer electronics, automotive, industrial controls, and laboratory equipment.
This product is a reliable choice for precision low-power amplification needs in various electronic systems. Browse through the Electronics & Electricals Semiconductor and Operational Amplifier categories on EnvMart for more options in Operational Amplifiers.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 1.3 MHz, providing stable amplification across frequencies.
It operates on a supply voltage range of 3 to 6 volts, making it suitable for low voltage applications.
This operational amplifier features four channels in one integrated circuit (IC).
The maximum operating temperature is 125°C, allowing it to function in harsh environments.
The package dimensions are approximately 8.75 mm in length, 4 mm in width, and 1.65 mm in height.
It has an electrostatic discharge tolerance of up to 2 kV, enhancing its robustness.
The input bias current is 95 nA, which helps minimize signal distortion.
It can provide an output current of 46 mA, suitable for general purpose amplification tasks.
The slew rate of this operational amplifier is 0.45 V/μs, which indicates how quickly it can respond to changes in input signal.
Yes, this operational amplifier is RoHS compliant, meeting environmental standards.
It is suitable for analog signal amplification, filtering, and conditioning circuits in consumer electronics, automotive, and industrial controls.
This operational amplifier uses a surface mount type, specifically in a 14-pin SOIC package.
