STMicroelectronics Operational Amplifier 1.3 MHz Gain Bandwidth Product 14-Pin SOIC Surface Mount LMV324IDT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | LMV324IDT |
| Width | 4mm |
| Mount Type | Surface |
| Series | LMV321 |
| Output Current | 46mA |
| Maximum Operating Temperature | 125°C |
| Package Type | SOIC |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 4 |
| Standards/Approvals | RoHS |
| Pay online using | Or choose to pay later via bank transfer |
| RS Stock No. | 714-7421Brand: STMicroelectronicsManufacturers Part No.: LMV324IDTDistrelec Article No.: 304-43-872 |
| Pin Count | 14 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 6V |
| Minimum Supply Voltage | 3V |
| GBP - Gain Bandwidth Product | 1.3MHz |
| Input Bias Current | 95 nA |
| Vos - Input Offset Voltage | 6 mV |
| Slew Rate | 0.45V/μs |
| Input Offset Current | 25 nA |
| Low supply current | 145 μA |
| Gain bandwidth product | 1 MHz |
| Electrostatic Discharge (ESD) tolerance | 2 kV |
Key Features
- Operates with supply voltage ranging from 3 V to 6 V for flexible power requirements.
- Low supply current consumption of 145 μA enables energy-efficient designs.
- Provides rail-to-rail input and output for improved signal handling in low-voltage circuits.
- Features a slew rate of 0.45 V/μs ensuring rapid response times in amplification.
- Wide operating temperature range from -40°C to 125°C supports robust industrial applications.
- Includes 4 channels within a 14-pin SOIC package for multi-channel analog signal processing.
- Gain bandwidth product of 1.3 MHz supports high-frequency operation.
- Input offset voltage of 6 mV and input bias current of 95 nA guarantees precise analog performance.
Product Description
STMicroelectronics LMV324IDT is a quad operational amplifier designed for general purpose use in electronic circuits requiring low power consumption and moderate frequency response. Featuring a gain bandwidth product of 1.3 MHz and rail-to-rail input and output stages, this device operates efficiently between 3 V and 6 V supply voltages, ideal for battery-operated and portable equipment.
The 14-pin SOIC surface mount package allows compact PCB layouts with four independent amplifier channels integrated in one device. Its low input bias current of 95 nA and input offset voltage of 6 mV ensure high accuracy for analog signal amplification tasks.
With a slew rate of 0.45 V/μs and electrostatic discharge tolerance of 2 kV, the LMV324IDT is capable of handling fast signal changes and robust against environmental electromagnetic disturbances. It supports a wide operating temperature range from -40°C to 125°C, making it suitable for automotive and industrial electronics applications meeting AEC-Q100 standards.
Operates from 3 V to 6 V supply voltage allowing use in low voltage designs. Low supply current of 145 μA enhances energy efficiency for battery-powered devices. Rail-to-rail input/output provides maximum signal swing capability.
Four amplification channels in a single 14-pin SOIC surface mount package. Gain bandwidth product of 1.3 MHz enables operation at moderate frequencies. Low input offset voltage and bias current for accurate signal processing.
Meets RoHS environmental compliance and automotive AEC-Q100 standards. Electrostatic discharge tolerance up to 2 kV for device protection. Wide operating temperature range from -40°C to 125°C for demanding environments. Suitable for industrial, automotive, and portable electronic applications.
Explore a wide range of semiconductor and Operational Amplifier products from STMicroelectronics and other top brands at EnvMart to support your diverse electronic design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of the LMV324IDT is 1.3 MHz, supporting moderate frequency operation.
It operates with a supply voltage ranging from 3 V to 6 V, allowing for flexible power requirements.
This operational amplifier features four independent channels integrated within a single 14-pin SOIC package.
The input offset voltage is 6 mV, ensuring high accuracy in analog signal processing tasks.
It supports a wide operating temperature range from -40°C to 125°C, making it suitable for robust industrial applications.
The LMV324IDT has a slew rate of 0.45 V/μs, allowing for rapid response times in amplification.
This model comes in a 14-pin SOIC surface mount package, which allows for compact PCB layouts.
It has an electrostatic discharge (ESD) tolerance of up to 2 kV, providing protection against environmental disturbances.
The input bias current is 95 nA, contributing to its precise analog performance.
The dimensions of this operational amplifier are 8.75 mm in length, 4 mm in width, and 1.65 mm in height.
The LMV324IDT meets the AEC-Q100 automotive standard, making it suitable for automotive applications.
The maximum output current for the LMV324IDT is 46 mA, allowing it to drive various loads effectively.
