TE Connectivity AMPMODU MOD II Series Right Angle Through Hole Pin Header 32 Contacts 2.54 mm Pitch 2 Row 1-826634-6
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polybutylene Terephthalate |
| Contact Material | Brass |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 32 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.2mm |
| Mating Pin Length | 6.7mm |
Key Features
- The connector features a right angle orientation suitable for compact PCB assemblies.
- It is unshrouded with brass contacts plated in gold for reliable electrical performance.
- The housing is made of durable Polybutylene Terephthalate material ensuring mechanical robustness.
- This header supports a current rating of 3A and voltage up to 750V.
- Designed for through-hole mounting to provide secure mechanical and electrical connection.
- With a tail pin length of 3.2 mm and mating pin length of 6.7 mm, it facilitates efficient soldering and mating.
- Operates reliably between -55°C and 105°C, suitable for a wide range of industrial applications.
- Ideal for automation, control equipment, telecommunications, medical instruments, and test equipment.
Product Description
TE Connectivity 1-826634-6 AMPMODU MOD II Series Right Angle Through Hole Pin Header features a double row of 32 unshrouded male contacts spaced at 2.54 mm pitch. This connector is designed with a robust Polybutylene Terephthalate housing and brass gold-plated contacts, ensuring durable and reliable electrical connections for industrial and commercial PCB applications.
The right angle orientation promotes compact board layouts, while its through-hole mount type secures it firmly to the PCB. The breakaway design allows tailoring the pin headers to the exact size needed, enhancing flexibility and reducing assembly time and costs.
Supporting a current rating of 3A and a maximum voltage of 750V, this pin header is suitable for demanding environments operating between -55°C and 105°C. It is ideal for use in automotive controls, telecommunications, industrial test equipment, medical devices, and storage solutions.
The connector system supports board-to-board and wire-to-board interfaces, ensuring compatibility across various electronic assemblies. Its solder termination type and defined tail pin and mating pin lengths facilitate efficient and reliable solder processes and connectivity.
The connector is unshrouded, providing ease of access for mating connectors. Brass contact material with gold plating ensures excellent conductivity and corrosion resistance. The robust housing material supports mechanical strength and thermal stability.
Right angle orientation suits compact and space-saving PCB designs. Breakaway rows enable custom sizing tailored to application needs. Designed for through-hole mounting, ensuring secure PCB attachment. Suited for a temperature range of -55°C to 105°C for versatile industrial use.
High voltage (750V) and current (3A) ratings support demanding electrical requirements.
This TE Connectivity AMPMODU Mod II series pin header is a reliable, economical solution for PCB interconnection in automation, industrial control, telecommunications, medical instrumentation, and multiple other electronic applications. It delivers both performance and flexibility needed in complex assemblies.
Browse more high-quality connectors and electronic components at EnvMart to support your design and manufacturing needs.
