STMicroelectronics Operational Amplifier 22 MHz Gain Bandwidth, 5-Pin SOT-23 Package TSB7191AIYLT
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.45mm |
| Length | 3mm |
| Model | TSB7191AIYLT |
| Width | 1.75mm |
| Mount Type | Surface |
| Low Noise | 12 nV/√Hz |
| Series | TSB7191A |
| Maximum Operating Temperature | 125°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 1 |
| Standards/Approvals | JEDEC, ANSI/ESD STM5.3.1 |
| Pin Count | 5 |
| Automotive Standard | AEC-Q3, AEC-Q100 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 22MHz |
| Input Bias Current | 0 nA |
| Slew Rate | 12V/μs |
| Input Offset Current | 10 nA |
| Extended temperature range | -40 °C to +125 °C |
Key Features
- Rail-to-rail input and output ensure full signal swing at low voltage.
- Operates over a wide supply voltage range from 2.7 V to 36 V.
- Low input offset voltage of maximum 300 µV enhances accuracy.
- High slew rate of 12 V/µs supports fast signal changes.
- Extended temperature range from -40 °C to 125 °C for automotive-grade reliability.
- Integrated EMI filters reduce noise and improve signal quality.
- Automotive AEC-Q3 and AEC-Q100 qualified for harsh environments.
- Single channel amplifier with 5 pins for easy PCB integration.
Product Description
STMicroelectronics TSB7191AIYLT is a high-performance operational amplifier featuring a 22 MHz gain bandwidth product and a compact 5-pin SOT-23 surface-mount package. Designed for precision analog signal processing, it supports supply voltages from 2.7 V up to 36 V, suitable for industrial and automotive applications.
The amplifier offers rail-to-rail input and output capability, enabling utilization of the full supply voltage range and providing greater dynamic range in low voltage systems. With a maximum input offset voltage of 300 µV at 25 °C and low input bias current, the device ensures high accuracy and stable signal amplification.
The fast slew rate of 12 V/µs allows this amplifier to handle rapid signal transitions effectively, making it ideal for filters, actuator drives, motor controls, hall effect sensors, and resistive transducer interfaces.
The device is qualified to automotive standards AEC-Q3 and AEC-Q100, proving its robustness and reliability in harsh environments. Its operational temperature range spans from -40 °C to +125 °C, further supporting a wide range of industrial, automotive, and instrumentation applications.
Additional features include integrated EMI filters to minimize electromagnetic interference and an extended supply voltage range. The compact dimensions of 3 mm length, 1.75 mm width, and 1.45 mm height ease PCB layout constraints and enhance space utilization.
This amplifier is perfect for demanding electronic circuits that require precision, speed, and stability across varying environmental conditions. Rail-to-rail input and output provide full voltage swing. Wide supply voltage range from 2.7 V to 36 V extends application scope.
Low input offset voltage and bias current improve signal accuracy. High slew rate supports fast signal response. Automotive AEC-Q3 and AEC-Q100 certified for durability. Extended operating temperature range from -40 °C to +125 °C.
Integrated EMI filtering enhances noise immunity. Compact 5-pin SOT-23 package for surface mount applications.
Explore the extensive range of Operational Amplifiers and related semiconductor components available on EnvMart to enhance your electronic designs with trusted brands like STMicroelectronics.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 22 MHz, allowing for effective signal amplification in various applications.
It operates over a wide supply voltage range from 2.7 V to 36 V, making it suitable for diverse industrial and automotive applications.
The maximum input offset voltage is 300 µV at 25 °C, which enhances the accuracy of signal amplification.
The slew rate is 12 V/µs, enabling it to handle rapid signal changes effectively.
This model has dimensions of 3 mm in length, 1.75 mm in width, and 1.45 mm in height, which aids in PCB layout and space utilization.
The operational temperature range spans from -40 °C to +125 °C, supporting its use in harsh environments.
This operational amplifier features a single channel design, making it suitable for various applications that require a compact solution.
It comes in a 5-pin SOT-23 surface-mount package, facilitating easy integration into PCB designs.
It is qualified to automotive standards AEC-Q3 and AEC-Q100, ensuring reliability in automotive applications.
The input bias current is 0 nA, which contributes to its high accuracy and stable performance.
Yes, it features integrated EMI filters that help reduce noise and improve signal quality in electronic circuits.
It meets JEDEC and ANSI/ESD STM5.3.1 standards, ensuring compliance with industry requirements.
