TDK EMC Filter B84143A0090R105 90 A 520V AC 50Hz/60Hz Flange Mount Screw Termination 3 Phase

TDK B84143A0090R105 is a high-performance EMC filter engineered to provide very high insertion loss, optimized specifically for long motor cables under full load conditions. This filter is designed for three-phase electrical drive systems, providing efficient EMI suppression to maintain signal integrity and reduce electromagnetic interference.

The filter supports a maximum current of 90 A and voltage of 520 V AC, operating reliably at standard industrial frequencies of 50 Hz and 60 Hz. Its flange mounting combined with screw termination ensures secure and easy installation in industrial setups.

With a minimal leakage current of 5 mA and resistance of just 1.1 milliohms, the filter maintains low power loss, enhancing energy efficiency. It is suitable for use in various industrial applications such as machine tools, conveyor belts, filling systems, robots, pumps, ventilation, and power supply units.

The compact dimensions (135 mm height, 290 mm depth, 80 mm length) make this device ideal for installations where space is limited, without compromising filtering performance. The filter operates within a temperature range of -25°C to 100°C, supporting demanding environments.

TDK B84143A0090R105 complies with UL 1283, CSA 22.2 No. 8, and EN 133200 standards, ensuring safety and conformity in industrial applications. This EMC filter provides a reliable solution for EMI mitigation in power line filtering tasks for electrical drives and related equipment.

Maximum current rating of 90 amperes for robust performance. Operates at a maximum voltage of 520 volts AC with frequencies of 50 and 60 Hz. Compact flange mount design for ease of installation in constrained spaces. Low leakage current of 5 mA ensures energy efficiency and safe operation.

Meets UL 1283, CSA 22.2 No. 8, and EN 133200 standards for quality and safety. Suitable for electrical drive units including machine tools, conveyor belts, filling systems, and robots. Operating temperature range from -25°C to 100°C for industrial environments.

Resistance value is low at 1.1 milliohms to minimize power loss. The product dimensions are 135 mm height, 290 mm depth, and 80 mm length for compact installation. Single stage EMI suppression filter optimized for flange mounting and screw termination.
