TE Connectivity AMPMODU MOD II Series Right Angle Through Hole Pin Header, 100 Contacts, 2.54 mm Pitch, 2 Row 5-826662-0
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 750V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 3A |
| Mount Type | Through Hole |
| Housing Material | Polyester |
| Contact Material | Brass |
| Series | AMPMODU MOD II |
| Termination Type | Solder |
| Maximum Operating Temperature | 105°C |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold |
| Number of Contacts | 100 |
| Contact Gender | Male |
| Shrouded/Unshrouded | Unshrouded |
| Connector System | Board-to-Board, Wire-to-Board |
| Tail Pin Length | 3.2mm |
| Mating Pin Length | 5.8mm |
Key Features
- The connector features a right angle orientation suitable for board-to-board or wire-to-board connections.
- It supports a current rating of 3A and a voltage rating of 750V for reliable performance.
- Constructed with brass contacts plated in gold, ensuring excellent conductivity and corrosion resistance.
- Housing made from durable polyester material, rated for operating temperatures from -55°C to 105°C.
- Designed for through-hole mounting with a solder termination type for solid mechanical and electrical attachment.
- Unshrouded design offers easy access for mating connectors and accommodates male contact gender pins.
- Contact pins measure 0.64 mm square, with a tail pin length of 3.2 mm and mating pin length of 5.8 mm, allowing for secure engagement.
- Modular 2.54 mm pitch standard ensures compatibility across a wide range of electronic equipment.
Product Description
TE Connectivity 5-826662-0 AMPMODU MOD II Series Right Angle Through Hole Pin Header is a premium electronic connector designed for demanding circuit board interconnections. With 100 unshrouded male contacts arranged in 2 rows and spaced at the industry standard 2.54 mm pitch, this component facilitates reliable and efficient signal transmission.
The header’s brass contacts are gold plated to enhance conductivity and to resist corrosion under industrial conditions. The housing is constructed from polyester, providing excellent thermal stability and mechanical strength across a wide operating temperature range from -55°C to 105°C.
Perfectly suited for board-to-board and wire-to-board applications, this connector supports a current rating of 3 amperes and voltage rating of up to 750 volts, making it ideal for use in electronic devices, industrial equipment, and manufacturing automation systems.
The pin header is mounted via through-hole solder termination, providing secure attachment for robust mechanical and electrical connections. The right angle orientation allows for versatile PCB layout and stacking configurations while preserving board space.
Pins are 0.64 mm square with a tail length of 3.2 mm and mating length of 5.8 mm. The modular design enables pins to be snapped to the required length, allowing customization for various assembly needs.
The connector features a right angle orientation suitable for board-to-board or wire-to-board connections. Supports a current rating of 3A and voltage rating of 750V. Brass contacts with gold plating provide excellent corrosion resistance.
Durable polyester housing rated for -55°C to 105°C operating temperature. Through-hole solder termination ensures strong mechanical and electrical bonds. Unshrouded male contacts with 0.64 mm square pins. Industrial-grade component suitable for electronics, manufacturing, and automation sectors.
Ideal for engineers and designers requiring reliable and configurable pin headers, the TE Connectivity AMPMODU MOD II series is recognized for its modularity and durability across industry sectors.
Explore EnvMart’s extensive range of electronic connectors and components to find compatible products and accessories that complement the 5-826662-0 pin header for your project requirements.
Explore more products in our PCB Headers category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The voltage rating of this pin header is 750V, making it suitable for a variety of electronic applications.
This model supports a current rating of 3A, allowing it to handle significant electrical loads in various applications.
The contacts are made of brass and are plated with gold to enhance conductivity and resist corrosion.
The operating temperature range for this connector is from -55°C to 105°C, ensuring reliable performance in extreme conditions.
This pin header features 100 contacts arranged in 2 rows, facilitating efficient signal transmission.
This connector is designed for through-hole mounting, providing a secure attachment to the PCB.
The pitch size of this pin header is 2.54 mm, which is a standard size for many electronic connectors.
The tail pin length of the contacts is 3.2 mm, allowing for secure engagement during installation.
The mating pin length of the contacts is 5.8 mm, designed for effective connection with compatible components.
This connector features a right angle orientation, suitable for both board-to-board and wire-to-board connections.
This model is unshrouded, which allows for easy access when mating with other connectors.
This pin header is suitable for board-to-board and wire-to-board applications in electronic devices and industrial equipment.
