Wurth Elektronik 3653 Series Pluggable Terminal Block 12-Contact 3.81 mm Pitch 1 Row 10A 2.5kV Horizontal Screw 691365310012

Free Delivery in India | Lowest Global Shipping Charges

Wurth Elektronik 3653 Series Pluggable Terminal Block 12-Contact 3.81 mm Pitch 1 Row 10A 2.5kV Horizontal Screw 691365310012

Name: Wurth Elektronik 3653 Series Pluggable Terminal Block 12-Contact 3.81 mm Pitch 1 Row 10A 2.5kV Horizontal Screw 691365310012
Brand: Wurth Elektronik
SKU: 335599
Price: 20.22 USD
Availability: InStock



Category Electronic Components, Power & Connectors Brand Wurth Elektronik Condition New

Specifications

Country of Origin	China
Voltage	2.5kV
Brand	Wurth Elektronik
Colour	Green
Orientation	Horizontal
Current	10A
Length	55.32mm
Depth	19.1mm
Width	10.4mm
Housing Material	Polyamide 66
Series	3653
Number of Rows	1
Pitch	3.81mm
Standards/Approvals	RoHS
Number of Contacts	12
Connector Gender	Male
Minimum Wire Size mm²	0.081mm²
Maximum Wire Size mm²	1.31mm²
Minimum Wire Size AWG	28AWG
Maximum Wire Size AWG	16AWG
Wire Connection Method	Screw

Key Features

Constructed with polyamide 66 housing offering durability and electrical insulation.
Rated for 10 amps current carrying capacity with a voltage rating of 2.5kV.
Designed with a single row and horizontal orientation for easy PCB mounting.
Utilizes screw wire connection method compatible with wire sizes 28 to 16 AWG.
Compact dimensions measuring 55.32 mm length, 10.4 mm width, and 19.1 mm depth.
Green colored terminal block for easy identification in assemblies.
Meets RoHS standards ensuring compliance with environmental regulations.
Manufactured in China maintaining quality control per Wurth Elektronik standards.

Product Description

Wurth Elektronik 691365310012 is a high-quality pluggable terminal block designed for reliable electrical connections in electronic and electrical assemblies. This terminal block features 12 contacts arranged in a single row with a 3.81 mm pitch, ideal for PCB mounting applications requiring compact and efficient connector solutions.

The housing is made from polyamide 66, offering excellent durability and electrical insulation properties. Rated to carry currents up to 10 amps and withstand voltages up to 2.5kV, it ensures operational safety and performance in demanding environments.

The terminal block employs a screw connection method to accommodate wire sizes ranging from 28 AWG (0.081 mm²) to 16 AWG (1.31 mm²), providing flexibility for various wiring requirements. Its horizontal orientation facilitates straightforward assembly and integration in electronics systems.

Its physical dimensions measure 55.32 mm in length, 10.4 mm in width, and 19.1 mm in depth, balancing compact form factor with ease of installation. The green color coding helps with quick identification and system organization.

Compliant with RoHS standards, this product supports environmental safety regulations, making it suitable for industrial, commercial, automation, and manufacturing use cases. Constructed with polyamide 66 housing providing durability and insulation.

Rated for 10 amp current and 2.5kV voltage handling capacity. Single-row, 12-contact configuration with 3.81 mm pitch. Screw wire connection compatible with 28 to 16 AWG wire sizes. Compact size of 55.32 mm length, 10.4 mm width, and 19.1 mm depth.

Green coloring for identification in assemblies. Meets strict RoHS environmental standards. Manufactured in China under quality control by Wurth Elektronik. This terminal block is widely suitable for electronic, power connector, automation, and industrial control applications requiring secure, pluggable wire connections.
