Microchip 16-bit PIC24E Microcontroller 256kB FLASH 60 MHz 44-Pin TQFP PIC24EP256MC204-I/PT

Microchip PIC24EP256MC204-I/PT is a high-performance 16-bit PIC24E microcontroller designed for precision motor control and general embedded applications. Operating at a maximum clock frequency of 60 MHz with a 256kB FLASH program memory and 32kB RAM, it combines energy efficiency with superior processing power.

The device features a modified Harvard architecture optimized for 16-bit wide data paths and 24-bit wide instructions, enhancing computational throughput and reducing latency in control and signal processing tasks. It also supports a rich set of peripherals including 9 channels of 12-bit analog-to-digital converters (ADCs), 4 analogue comparators, and a single 4-bit digital to analog converter (DAC), allowing versatile sensor interfacing and analog signal management.

Communication is facilitated via QEI and SPI interfaces, making it suitable for complex embedded network communication and sensor data acquisition. This microcontroller is packaged in a 44-Pin Thin Quad Flat Package (TQFP) measuring approximately 10 mm by 10 mm by 1.05 mm, optimized for surface mounting on compact PCBs.

Designed to meet automotive standards including AEC-Q100, it guarantees robustness and reliability for automotive and industrial applications requiring extended temperature operation from -40°C to 85°C and supply voltages ranging between 3.0V to 3.6V.

With 2 integrated timers and extensive on-chip peripherals optimized for motor control applications, this device supports efficient and quiet operation of brushless DC, permanent magnet synchronous, AC induction, and stepper motors.

Operates at maximum clock frequency of 60 MHz with a 16-bit modified Harvard architecture core. Includes 256kB FLASH memory and 32kB RAM providing large storage capacity. 9 channels of 12-bit ADCs and 4 analogue comparators for advanced analog signal processing.

Communication via QEI and SPI interfaces allows integration with complex systems. AEC-Q100 automotive qualification ensures suitability for automotive and harsh environments. Package: 44-Pin Surface Mount TQFP, dimensions 10 mm x 10 mm x 1.05 mm.

Operating voltage range of 3.0V to 3.6V supports various embedded applications.

This Microcontroller is ideal for industrial, automotive, consumer electronics, and embedded system applications requiring high precision and durability. Explore the Microchip range in EnvMart to find compatible development hardware and software support tools.
