| Country of Origin | China |
|---|---|
| Brand | Nexperia |
| Height | 1.1mm |
| Length | 3mm |
| Model | BZX84-C3V6,215 |
| Mount Type | Surface |
| Series | BZX84 |
| Maximum Operating Temperature | 150°C |
| Package Type | SOT-23 |
| Minimum Operating Temperature | -65°C |
| Pin Count | 3 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 250mW |
| Diode Configuration | Single |
| Test Current It | 5mA |
| Maximum Reverse Leakage Current | 5μA |
| Nominal Zener Voltage Vz | 3.6V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 90Ω |
| Typical Voltage Temperature Coefficient | -2.4mV/°C |
| onsemi 1, 3.6 V Zener Diode, Single 300 mW 6 % Surface 3-Pin SOT-23Brand | onsemi |
Nexperia BZX84-C3V6,215 is a high-quality single Zener diode designed for effective voltage regulation in electronic circuits. Featuring a nominal zener voltage of 3.6 V and a maximum power dissipation of 250 mW, it is ideal for protecting sensitive components by stabilizing voltage supply.
This Zener diode is surface mounted in a compact 3-pin SOT-23 package, enabling space-saving PCB designs and ease of assembly in automated manufacturing processes. It provides a voltage tolerance of ±5%, ensuring precise voltage regulation across diverse operating conditions.
Operating reliably within a temperature range from -65°C to 150°C, this diode is capable of withstanding harsh industrial and automotive environments. The maximum zener impedance of 90 Ω at 5 mA test current guarantees stable voltage behavior under typical load conditions.
The diode features a maximum reverse leakage current of only 5 μA, minimizing unwanted current flow and enhancing circuit efficiency. Certification to automotive standard AEC-Q101 further confirms its suitability for use in automotive electronic systems.
Single diode configuration for simple voltage regulation solutions. Nominal zener voltage of 3.6 V with ±5% tolerance for precise operation. Maximum power dissipation rated at 250 mW for reliable protection. Compact 3-pin SOT-23 surface mount package for efficient PCB layout.
Wide operating temperature range from -65°C to 150°C suitable for automotive use. Low reverse leakage current of 5 μA to maintain circuit integrity. Compliance with AEC-Q101 automotive standard ensuring quality and durability.
This Zener diode is widely used in industrial, automotive, telecommunications, and general electronic applications requiring stable voltage regulation and protection. Its robust performance characteristics make it a reliable choice for designers needing consistent semiconductor discrete components.
