Omron Power Relay PCB Mount 24V dc Coil 10A Switching Current SPDT G5Q-1 DC24 (TY)

Omron G5Q-1 DC24 (TY) Power Relay is a high-performance single pole double throw (SPDT) PCB mount relay operating with a 24V dc coil voltage and capable of switching currents up to 10A. Its compact size (20.3mm length, 15.8mm height, and 10.3mm width) makes it ideal for space-constrained PCB applications.

The relay features a coil resistance of 1.4kΩ with low power consumption of 4kW, allowing for efficient operation. It maintains excellent electrical isolation with a high withstand voltage rating of 8 kV between coil and contacts, supporting reliable operation under challenging electrical environments.

Designed for usage across a wide temperature range from -40°C to 85°C, this relay uses durable silver alloy contacts offering excellent conductivity and long operational life. The solder-type terminals facilitate robust PCB mounting ensuring secure mechanical and electrical integrity in installed configurations.

This Omron power relay supports switching AC voltages up to 400V and a maximum switching power of 1.25kVA, suitable for various industrial and commercial electronic control systems. It conforms to global standards such as UL, RoHS, IEC, EN, and CE, providing assurance of compliance and quality.

Applications include electrical automation, industrial equipment control panels, signal conditioning circuits, and other PCB-based relay switching needs in manufacturing, HVAC, instrumentation, and electrical systems.

This product extends the trusted G5Q series line known for its reliability and compact design optimized for demanding industrial environments. This relay offers high isolation between coil and contacts ensuring reliable performance.

It has a compact form factor with dimensions 20.3mm x 15.8mm x 10.3mm. The coil consumes low power with a resistance of 1.4kΩ and power rating of 4kW. Designed to operate in temperatures ranging from -40°C to 85°C. Silver alloy contact material provides durability and improved conductivity.

Suitable for PCB mounting with solder terminal type for secure connections. Capable of switching AC voltages up to 400V ac with a maximum switching power of 1.25kVA. Complies with international standards including UL, RoHS, IEC, EN, and CE ensuring safety and quality.
