TDK Flange EMC Filter 30 A 250V AC/DC 60Hz Screw Termination 1 Phase B84142A0030R000

Free Delivery in India | Lowest Global Shipping Charges

TDK Flange EMC Filter 30 A 250V AC/DC 60Hz Screw Termination 1 Phase B84142A0030R000



Category Electronic Components, Power & Connectors Brand TDK Condition New

Specifications

Country of Origin	China
Brand	TDK
Height	68mm
Length	105mm
Model	B84142A0030R000
Depth	130mm
Mount Type	Flange
Operating Frequency	60Hz
Series	B84142A
Maximum Operating Temperature	100°C
Number Of Stages	2
Resistance	5mΩ
Minimum Operating Temperature	-25°C
Maximum Current	30A
Number of Phases	1
Leakage Current	7.9mA
Maximum Voltage	250V ac/dc
Standards/Approvals	UL1283
Termination Style	Screw

Key Features

Compact flange mount construction ensuring easy installation.
Optimized for motor cables under full load with very high insertion loss performance.
Low leakage current of 7.9 mA improving energy efficiency.
Operates effectively between -25°C and 100°C ambient temperature.
Two-stage filter series providing reliable EMI suppression.
Compliance with UL1283 and CSA22.2 No. 8 standards for safety and performance.
Resistance is low at 5 mΩ ensuring minimal voltage drop.
Protection rating IP20 suitable for industrial and electronic environments.

Product Description

TDK B84142A0030R000 flange EMC filter is a highly compact, two-line EMI suppression device designed for powering electrical systems such as lifts, conveyor belts, pumps, ventilation systems, and power supply units in industrial and commercial applications. It offers a maximum current handling of 30 A and supports AC/DC voltage up to 250V with a 60Hz operating frequency. The screw termination and flange mount type ensure secure, reliable connectivity and easy assembly.

This filter features a low leakage current rating of 7.9 mA and a resistance of 5 mΩ, delivering very high insertion loss optimized for extensive motor cable lengths under full load conditions. Certified to UL1283 and CSA22.2 No. 8 (construction) standards, it guarantees robustness and safety in demanding electrical environments.

The filter operates efficiently within a temperature range of -25°C to 100°C, maintaining performance stability even under thermal stress. The product dimensions of 105 mm length, 130 mm depth, and 68 mm height provide a compact footprint for space-limited installations. It is intended for 1-phase power line EMI noise filtering with 2 filter stages to ensure superior electromagnetic compatibility.

Compact flange mount design for convenient installation. Ideal for use with motors and industrial automation equipment. Low leakage current enhances overall system efficiency. High insertion loss reduces EMI effectively across power line circuits.

Conforms to industry safety standards UL1283 and CSA22.2 No. 8. Durable construction suitable for industrial and manufacturing environments. IP20 protection rating provides basic protection against solid objects. Manufactured in China ensuring adherence to international quality norms.

This product is essential for professionals requiring reliable EMI filtering solutions in electronics, power systems, HVAC systems, manufacturing plants, and laboratory instrumentation. It is listed under the EMC Filters category for electronic components.
