Crydom Solid State Relay PCB Mount, 25 A Load Current, 530 V AC Load Voltage, 32V Control PFE380D25

Crydom PFE380D25 solid state relay is a high-quality PCB mount relay designed to switch AC loads up to 25 amps at voltages up to 530 V AC. It features zero-cross switching to reduce electrical noise and minimize stress on connected circuits. With a compact dimension of 43.1 mm length, 22.8 mm width, and 34.3 mm height, it fits easily onto standard PCBs using through hole terminals.

The relay operates with a control voltage range from 15 V DC up to a maximum of 32 V DC and supports a minimum load voltage of 48 V AC. It also supports surge current peaks up to 250 A, ensuring reliable short-term performance during high inrush currents. This device exhibits very low leakage currents when off, enhancing efficiency and safety in sensitive electronics.

Designed for a wide temperature operating range from -30°C to 80°C, the PFE380D25 is suitable for demanding industrial, automation, electrical control systems, and manufacturing applications. Its compliance with RoHS standards assures environmentally friendly manufacturing and usage.

The solid state relay's robust current and voltage characteristics make it an ideal choice for applications requiring high reliability and low maintenance, such as motor controls, HVAC systems, and process control equipment.

Designed for PCB mounting with through hole terminals. Supports a maximum load current of 25 amps. Maximum load voltage rating of 530 volts AC. Operating control voltage range from 15 V DC up to 32 V DC. Zero cross switching function reduces electrical noise.

Operating temperature range from -30°C to 80°C. Compact dimensions: 43.1 mm length, 22.8 mm width, 34.3 mm height. Surge current peak up to 250 amps. RoHS compliant for environmental safety.
