Crydom EZ Series Solid State Relay Panel Mount 18 A Load 280 Vrms Load 32 V dc Control EZE480D18

Crydom EZE480D18 Solid State Relay is a high-quality panel mount SSR designed for demanding industrial and automation applications. It supports a maximum load current of 18 A and can handle load voltages up to 280 Vrms, making it ideal for controlling medium to heavy electrical loads with greater reliability.

The relay features a compact design measuring 66.8 mm in length and 24.1 mm in both width and height, enabling integration into tight control panels and electrical enclosures. It utilizes 1/4" fast-on terminals allowing for quick and secure installation in industrial setups.

This model operates with DC control voltages from 15 V to 32 V and incorporates zero cross switching technology, significantly reducing electrical noise and wear on connected equipment during switching cycles. The output is realized through an SCR, providing silent operation without mechanical parts subject to failure.

Certified to international standards such as VDE, UL, RoHS, CSA, and CE (EN60950-1 compliance), this solid state relay ensures compliance with global safety and environmental regulations. It features low off state leakage current of 0.1 mArms and an 8 pF capacitance, supporting efficient and stable operation under varying electrical conditions.

Its operational temperature range from -40°C to 80°C allows deployment in a wide range of industrial environments including manufacturing, automation machinery, HVAC systems, and building controls. The relay is designed for AC load switching with a contact configuration of SPST (Single Pole Single Throw), making it versatile for numerous control applications.

Note: Heat sink is not included.

This Crydom EZ Series Solid State Relay provides a reliable and durable solution for modern industrial and electrical control applications where silent switching and long life are critical.

Supports 18 A maximum load current at 280 Vrms for robust heavy load handling. Compact panel mount form factor for efficient space utilization. 1/4" fast-on terminals enable fast installation and serviceability. Zero cross switching minimizes switching noise and prolongs load life.

Wide operating temperature range suits diverse industrial environments. Certified for safety and environmental compliance with UL, CSA, VDE, RoHS, and CE. Low off state leakage current reduces energy loss when relay is off.

SCR output ensures silent and wear-free switching. Suitable for industrial automation, HVAC, manufacturing, and control panels. Refer to datasheets for heat sink requirements and current derating guidelines. Explore more products in the Solid State Relay category on EnvMart for comprehensive industrial and automation control solutions.
