Maxim Integrated CMOS TTL Line Transceiver, Inverting, 28-Pin SOIC MAX211CWI+
Specifications
| Country of Origin | India |
|---|---|
| Brand | Maxim Integrated |
| Height | 2.65mm |
| Length | 18.1mm |
| Model | MAX211CWI+ |
| Width | 10.65mm |
| Mount Type | Surface |
| Output type | CMOS |
| Series | MAX211 |
| Input Type | Single Ended |
| Maximum Operating Temperature | 70°C |
| Package Type | SOIC |
| Minimum Operating Temperature | 0°C |
| Polarity | Inverting |
| IC Type | Line Transceiver IC |
| Pin Count | 28 |
| Maximum Supply Voltage | 5V |
| Logic Family | CMOS/TTL |
| Logic Function | Converter, Driver, Line Driver |
| Minimum Supply Voltage | -0.3V |
| Maximum High Level Output Current | 60mA |
| Maximum Propagation Delay Time @ CL | 10μs |
| Supply Current | 20mA |
| Maximum Low Level Output Current | 10mA |
Key Features
- The device supports CMOS and TTL logic families with inverting output polarity.
- It comes in a 28-pin small-outline integrated circuit package (SOIC) designed for space-saving applications.
- Operates with a minimum supply voltage of -0.3V and a maximum of 5V.
- Maximum output currents are 60mA (high level) and 10mA (low level) suitable for driving line signals.
- Maximum propagation delay time at capacitive load is 10 microseconds ensuring timely data transfer.
- Designed to operate in temperature range from 0°C to 70°C.
- Compact physical dimensions with length 18.1mm, width 10.65mm, and height 2.65mm.
- Supply current draw is 20mA ideal for low power applications.
Product Description
Maxim Integrated MAX211CWI+ is a CMOS TTL line transceiver IC with inverting functionality available in a 28-pin SOIC package. It integrates a charge pump circuitry enabling operation from a single +5V supply, simplifying design and power requirements.
This transceiver IC is ideal for balanced line communication where signal inversion and reliable line driving are needed. The device supports both CMOS and TTL logic families, delivering high-level output currents up to 60mA and low-level currents of 10mA, suitable for driving differential data lines.
The propagation delay time at a typical capacitive load of 10μs ensures swift data transfer, making it suitable for data rates exceeding 120 kbps. Its compact SOIC footprint measures 18.1mm by 10.65mm with a height of 2.65mm, helping reduce board space in high-density designs.
Designed for surface mount applications, this transceiver operates reliably in ambient temperatures ranging from 0°C to 70°C and consumes a supply current of 20mA, ideal for power-sensitive industrial, laboratory, and embedded communication systems.
This product lacks specific automotive certifications but is suitable for various electronic component applications including line interface and data communication IC systems. The IC features a single-ended input and CMOS output type with inverting polarity.
It uses surface mount technology optimized for small footprint circuit boards. The MAX211 series provides effective line driver and converter capabilities. Robust construction without external component requirements simplifies system integration.
This product is essential for industrial, communication, laboratory, and electronic manufacturing applications.
Maxim Integrated MAX211CWI+ is a key component in Line Transceiver IC applications and can be browsed via EnvMart’s dedicated semiconductor and interface IC categories for related parts and compatible devices.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum supply voltage for this model is 5V.
It operates reliably in ambient temperatures ranging from 0°C to 70°C.
The dimensions of this unit are 18.1mm in length, 10.65mm in width, and 2.65mm in height.
This model features a CMOS output type with inverting polarity.
The maximum high-level output current is 60mA.
The maximum propagation delay time at a capacitive load is 10 microseconds.
It supports both CMOS and TTL logic families.
The supply current draw is 20mA, making it suitable for low power applications.
This unit has a single-ended input type.
It comes in a 28-pin small-outline integrated circuit (SOIC) package.
It is suitable for industrial, communication, laboratory, and electronic manufacturing applications.
It integrates charge pump circuitry enabling operation from a single +5V supply.
