Maxim Integrated 1 Voltage Supervisor 8-Pin 3.3 V SOIC DS1706LESA+

Maxim Integrated DS1706LESA+ is a voltage supervisor designed for microprocessor supervisory and reset functions, delivered in an 8-pin SOIC package. It operates at a reset threshold voltage of 3.3 V, making it suitable for systems that require reliable voltage monitoring and reset capabilities over a wide operating temperature range from -40°C to 85°C.

This integrated circuit provides a watchdog timer to detect system malfunctions and includes manual reset capability, allowing users to trigger resets manually. The output drivers support both active low and active high signals, providing flexible interfacing options with microprocessors and digital circuits.

The device monitors a supply voltage range from 1.2 V to 5.5 V and is designed to supervise a monitored voltage of 4.75 V. It exhibits a reset active time of 285 ms, ensuring that systems are reset only after detecting stable voltage conditions. With dimensions of approximately 5 mm in length, 6.2 mm in width, and 1.75 mm in height, it facilitates compact system layouts via surface mount technology.

Typical use cases include desktop computers, laptops, notebooks, test and measurement instruments, portable battery-powered equipment, and multiple-output power supplies, contributing to enhanced system reliability through power supply monitoring and reset supervision.

Features watchdog timer for system activity monitoring. Supports manual reset for user-controlled operations. Active low and active high output drivers for versatile interfacing. Wide operating temperature range ensures durability in industrial environments.

Low minimum supply voltage allows operation in low power systems. Small SOIC surface mount package for space-efficient PCB design. Reliable reset active timing stabilizes system power sequencing. Designed for microprocessor supply voltage supervisory applications.

Ideal for various industrial and electronics applications including power management ICs.

Maxim Integrated offers this voltage supervisor as a high-quality solution for voltage monitoring and reset circuit needs in electronic and industrial equipment design. Explore our category of Voltage Supervisors to find complementary power management ICs.
