STMicroelectronics Voltage Supervisor 3 V 1 Supervisor 5-Pin SOT-23 STM6322SWY6F

Free Delivery in India | Lowest Global Shipping Charges

STMicroelectronics Voltage Supervisor 3 V 1 Supervisor 5-Pin SOT-23 STM6322SWY6F

Name: STMicroelectronics Voltage Supervisor 3 V 1 Supervisor 5-Pin SOT-23 STM6322SWY6F
Brand: STMicroelectronics
SKU: 183828
Price: 0.85 USD
Availability: InStock



Category Voltage Supervisors Brand STMicroelectronics Condition New

Specifications

Country of Origin	India
Voltage	Supervisors STMicroelectronics 1 Voltage Supervisor 5-Pin 3 V SOT-23 RS Stock No
Brand	STMicroelectronics
Height	1.15mm
Length	2.9mm
Model	STM6322SWY6F
Width	1.6mm
Mount Type	Surface
Series	STM632
Maximum Operating Temperature	85°C
Package Type	SOT-23
Sub Type	Microprocessor Supervisory Circuit
Minimum Operating Temperature	-40°C
Pin Count	5
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	1V
Number of Supervisors	1
Output Driver	Active Low, Open Drain, Active High, Push Pull
Reset Threshold Voltage	3V
Monitored Voltage	2.93V
Reset Active Time	280ms

Key Features

Monitors supply voltage with a reset threshold voltage of 3 V.
Includes a manual reset function but no watchdog timer.
Output driver supports active low open drain and active high push pull outputs.
Compact 5-pin SOT-23 surface mount package for space-saving PCB designs.
Operates reliably over a temperature range of -40°C to 85°C.
Suitable for desktop, laptop, notebook computers, and portable devices.
Low height of 1.15 mm, length of 2.9 mm, and width of 1.6 mm.
Minimum supply voltage of 1 V and maximum supply voltage of 5.5 V.

Product Description

STMicroelectronics STM6322SWY6F Voltage Supervisor 3 V 1 Supervisor 5-Pin SOT-23 is a highly reliable microprocessor supervisory circuit designed to monitor and manage supply voltage levels in electronic systems. This device features a reset threshold voltage of 3 V and includes manual reset capability for improved control. It does not include a watchdog timer but offers an output driver capable of both active low open drain and active high push pull outputs.

Packaged in a compact 5-pin SOT-23 surface mount package, the supervisor IC is optimized for space-constrained applications such as desktop computers, laptops, notebooks, and portable battery-powered equipment. It effectively safeguards electronic systems by ensuring the supply voltage remains within acceptable limits with a minimum supply voltage of 1 V and a maximum of 5.5 V.

The device’s operating temperature range from -40°C to 85°C makes it suitable for industrial and commercial environments. Its small dimensions - 1.15 mm in height, 2.9 mm length, and 1.6 mm width - allow for flexible PCB layout options in various manufacturing and testing instrumentation systems.

Monitors microprocessor supply voltage and provides reset signals. Manual reset functionality enhances system control. Output driver supports multiple output configurations for versatile usage. SOT-23 5-pin surface mount package ensures compact PCB design.

Wide operating temperature range from -40°C to 85°C for reliability. Applicable in desktop, laptop, notebook computers, and portable devices. Low profile with small dimensions facilitates space-saving installation. Operating voltages from 1 V to 5.5 V accommodate various power supply designs.

This STMicroelectronics voltage supervisor is ideal for systems requiring precise supply voltage monitoring and reliable reset functions to prevent improper operation or damage during voltage irregularities. It finds extensive applications in industrial, laboratory, computing, and manufacturing settings where voltage supervision is critical.
