Maxim Integrated 1 Voltage Supervisor Microprocessor Supervisory Circuit 8-Pin SOIC 3.15V MAX706TESA+

Free Delivery in India | Lowest Global Shipping Charges

Maxim Integrated 1 Voltage Supervisor Microprocessor Supervisory Circuit 8-Pin SOIC 3.15V MAX706TESA+

Name: Maxim Integrated 1 Voltage Supervisor Microprocessor Supervisory Circuit 8-Pin SOIC 3.15V MAX706TESA+
Brand: Maxim Integrated
SKU: 159935



Category Voltage Supervisors Brand Maxim Integrated Condition New

Specifications

Country of Origin	United States
Brand	Maxim Integrated
Height	1.5mm
Length	5mm
Model	MAX706TESA+
Width	4mm
Mount Type	Surface
Series	MAX706T
Maximum Operating Temperature	85°C
Package Type	SOIC
Sub Type	Microprocessor Supervisory Circuit
Minimum Operating Temperature	-40°C
Pin Count	8
Maximum Supply Voltage	5.5V
Minimum Supply Voltage	1.2V
Number of Supervisors	1
Output Driver	Active Low, Push Pull
Reset Threshold Voltage	3.15V
Monitored Voltage	4.4V
Reset Active Time	280ms

Key Features

Features a single supervisor with a reset threshold voltage of 3.15V.
Equipped with watchdog timer and manual reset functionalities for reliable operation.
Active low, push-pull output driver ensures precise reset signaling.
Compact 8-pin SOIC surface mount package with dimensions 5mm length x 4mm width x 1.5mm height.
Operates over a wide temperature range from -40°C to 85°C for enhanced reliability.
Monitors voltages up to 4.4V with minimum supply voltage of 1.2V and maximum supply voltage of 5.5V.
Reset active time of 280 milliseconds to ensure stable system reset.
Ideal for use in microprocessor supervision, power supply monitoring, and portable battery-powered equipment.

Product Description

Maxim Integrated MAX706TESA+ is a precise 1 voltage supervisor microprocessor supervisory circuit tailored for desktop, laptop, notebook computers, and portable battery-powered equipment. Featuring an 8-pin SOIC surface-mount package, it efficiently monitors supply voltages and provides manual reset and watchdog timer capabilities.

Operating over a temperature range of -40°C to 85°C, it supports supply voltages from 1.2V minimum to 5.5V maximum with a reset threshold voltage fixed at 3.15V. The integrated active low, push-pull output driver ensures reliable system resets with a reset active time of 280 milliseconds.

This voltage supervisor is suitable for power fail detection and reset monitoring in microprocessor and microcontroller applications. The compact 5mm by 4mm package, complemented with a height of just 1.5mm, facilitates PCB space savings and surface mounting ease.

Features include watchdog timer and manual reset for enhanced system reliability. Designed specifically for power supply monitoring and supervisory applications. Provides supply voltage detection ensuring system integrity.

Ideal for industrial, computer, communication, and test instrumentation environments. Output driver configured for active low, push-pull operation. Manufactured in the United States, ensuring compliance with high quality standards.

Overall, the MAX706TESA+ delivers robust, reliable supervision of power supply voltages for microprocessor-based systems, suitable for various industrial, laboratory, and commercial electronic applications. Explore additional Maxim Integrated Voltage Supervisors and power management ICs for complementary solutions at EnvMart.
