Omron Screw Mount Din Track Power Relay 24V DC Coil Voltage 25A Switching Current G7Z-3A1B-11Z-R DC24
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Omron |
| Height | 62mm |
| Length | 45mm |
| Model | G7Z-3A1B-11Z-R DC24 |
| Width | 92.2mm |
| Mount Type | Screw, DIN Track |
| Contact Material | Silver Alloy |
| Series | G7Z |
| Maximum Operating Temperature | 60°C |
| Contact Configuration | 3PST-NO, SPST-NC |
| Minimum Operating Temperature | -25°C |
| Switching Current | 25A |
| Terminal type | Screw |
| Contact Resistance | 400mΩ |
| Standards/Approvals | RoHS |
| Coil Resistance | 156Ω |
| Coil Voltage | 24V dc |
| Switching DC Voltage | 125V dc |
| Switching AC Voltage | 480V |
| Coil Power | 3.7W |
Key Features
- The relay supports a 25A switching current suitable for high-load circuit applications.
- It operates at switching voltages up to 480V AC and 125V DC for versatile power handling.
- Coil power consumption is 3.7W with a coil resistance of 156 ohms ensuring efficient operation.
- The contacts are made of durable silver alloy offering reliable and long-lasting conductivity.
- The relay is mountable via screw terminals and fits DIN track configurations for modular installations.
- Operating temperature ranges from -25°C to 60°C, suitable for various industrial environments.
- Contact resistance is limited to 400 milliohms to minimize voltage drops and heating.
- The product is RoHS compliant, ensuring environmentally responsible manufacturing.
Product Description
Omron G7Z-3A1B-11Z-R DC24 Power Relay is a compact electromechanical switching device designed for industrial control systems and automation tasks. Operating with a 24V DC coil, it supports a 25A switching current, making it suitable for high-load circuit control and reliable power switching.
This power relay supports switching up to 480V AC and 125V DC, enabling use in both AC distribution and DC power control scenarios such as battery-backed systems. It features silver alloy contacts which provide durable conductive performance, ensuring long service life in demanding applications.
The relay mounts easily using screw terminals and can be installed on standard DIN tracks, enabling modular panel construction and simple retrofit installations. With an operating temperature range from -25°C to 60°C, it is rated for varied industrial indoor environments.
Design advantages include a coil power of 3.7W and a coil resistance of 156 ohms, offering predictable coil drive requirements and efficient operation. The contact resistance is minimal at 400 milliohms, reducing voltage drops and heating during switching.
The product complies with RoHS environmental standards, limiting hazardous substances and supporting sustainable manufacturing practices.
Typical industrial applications include motor control circuits requiring high current capacity, automation relay racks on DIN rails, AC distribution line switching, and DC power control systems. Its screw and DIN track mounting options facilitate flexible panel layouts in control cabinets.
This power relay is engineered in Japan to meet strict quality and reliability standards. Explore EnvMart's Electronics & Electricals categories for more Power Relays and control components suitable for industrial automation and electrical systems.
The relay supports a 25A switching current suitable for high-load circuit applications. It operates at switching voltages up to 480V AC and 125V DC for versatile power handling. Coil power consumption is 3.7W with a coil resistance of 156 ohms ensuring efficient operation.
The contacts are made of durable silver alloy offering reliable and long-lasting conductivity. The relay is mountable via screw terminals and fits DIN track configurations for modular installations. Operating temperature ranges from -25°C to 60°C, suitable for various industrial environments.
Contact resistance is limited to 400 milliohms to minimize voltage drops and heating. The product is RoHS compliant, ensuring environmentally responsible manufacturing. Ideal for motor control, relay rack automation, AC and DC power switching, and retrofit panel applications.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a switching current capacity of 25A, making it suitable for high-load circuit applications.
This relay operates at switching voltages up to 480V AC and 125V DC, providing versatility for different power handling scenarios.
The coil voltage is 24V DC with a power consumption of 3.7W, ensuring efficient operation.
The contacts are made of silver alloy, which provides reliable and long-lasting conductivity.
It can be mounted via screw terminals and fits standard DIN track configurations for modular installations.
The operating temperature ranges from -25°C to 60°C, suitable for various industrial environments.
The contact resistance is limited to 400 milliohms, which helps minimize voltage drops and heating during operation.
The dimensions are 62mm in height, 45mm in length, and 92.2mm in width.
It features a 3PST-NO (three-pole single-throw normally open) and SPST-NC (single-pole single-throw normally closed) contact configuration.
Yes, it is RoHS compliant, ensuring that it meets environmental standards by limiting hazardous substances.
Typical applications include motor control circuits, automation relay racks on DIN rails, and AC/DC power control systems.
It is manufactured in Japan, meeting strict quality and reliability standards.
