Crydom Panel Mount Solid State Relay, 25A Load Current, 660V AC Load, 32V DC Control H16WD
Specifications
| Country of Origin | India |
|---|---|
| Brand | Crydom |
| Height | 58.4mm |
| Length | 45.7mm |
| Model | H16WD |
| Mount Type | Panel |
| Output type | SCR |
| Series | H16WD |
| Maximum Operating Temperature | 80°C |
| Capacitance | 8pF |
| Minimum Operating Temperature | -40°C |
| Terminal type | Screw |
| Maximum Load Current | 25A |
| Standards/Approvals | RoHS |
| Maximum Load Voltage | 660V ac |
| Minimum Load Voltage | 48V ac |
| Minimum Control Voltage | 4V dc |
| Maximum Control Voltage | 32V dc |
| Off State Leakage Current | 1mA |
Key Features
- Supports panel mounting for secure installation.
- Provides high breakdown voltage and noise immunity for surge protection.
- Operates within a temperature range of -40°C to 80°C.
- Features a screw terminal for reliable electrical connections.
- Includes LED indicator for operational status.
- Offers zero-cross for resistive loads and random-fire output for inductive loads.
- Compact hockey puck style casing with SCR output suitable for heavy industrial loads.
- Complies with RoHS standards ensuring environmental safety.
Product Description
Crydom H16WD6025G Panel Mount Solid State Relay is engineered to handle industrial and automation tasks requiring robust electrical switching with a maximum load current of 25A and a high load voltage of up to 660V AC. With a 32V DC control voltage, the H16WD series offers superior electrical noise immunity and high voltage surge tolerance, making it ideal for demanding operational environments.
This relay is designed in a compact hockey puck style casing and features SCR output ideal for heavy industrial load switching. The panel mount configuration facilitates secure installation in control panels and industrial machines.
Key operational features include zero-cross switching for resistive loads to minimize electrical noise, and random-fire operation for inductive loads providing flexible use cases. The relay operates efficiently in extreme temperatures ranging from -40°C to 80°C, ensuring reliable function under harsh environmental conditions.
The unit includes a screw terminal design for stable electrical connections and LED indicators to monitor the relay status easily. Compliance with RoHS standards verifies the relay's environmentally safe manufacturing process.
Supports panel mounting for secure installation. High breakdown voltage and noise immunity for surge protection. Operating temperature range from -40°C to 80°C ensures durability. Screw terminal type for reliable electrical connections.
LED indicator for monitoring operational status. Zero-cross switching for resistive loads and random-fire operation for inductive loads. Compact hockey puck style casing with SCR output suitable for heavy industrial loads.
RoHS compliant ensuring environmental safety.
This relay is suitable for industrial automation, electrical control systems, process control equipment, and manufacturing machinery, offering dependable control with long service life. Explore a wide range of Solid State Relays and related electrical components within EnvMart’s extensive industrial electrical category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum load current for this model is 25A.
It supports a maximum load voltage of 660V AC.
The control voltage range for this relay is between 4V DC and 32V DC.
This relay operates efficiently within a temperature range of -40°C to 80°C.
It features a screw terminal design for reliable electrical connections.
Yes, it includes an LED indicator to monitor the operational status.
It provides SCR output, suitable for heavy industrial load switching.
This model is designed for panel mounting, facilitating secure installation.
The dimensions are 58.4mm in height and 45.7mm in length.
Yes, it complies with RoHS standards, ensuring environmental safety.
It offers zero-cross switching for resistive loads and random-fire operation for inductive loads.
The off-state leakage current is 1mA.
