| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C9V1YL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 100nA |
| Nominal Zener Voltage Vz | 9.1V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 100Ω |
| Typical Voltage Temperature Coefficient | 3.8mV/K |
Nexperia BZX8850S-C9V1YL is a high-quality 9.1 V voltage regulator Zener diode in a compact 2-pin DFN1006BD-2 surface mount package, designed for applications requiring precise voltage regulation with low power dissipation.
This single element diode offers a nominal Zener voltage of 9.1 V with ±5% tolerance and a maximum power dissipation of 365 mW, making it ideal for low current and battery-powered systems. The small form factor (1 mm length and 0.47 mm height) enables efficient PCB space utilization.
Its low test current of 50 μA and maximum reverse leakage current of 100 nA allow it to operate with minimal energy losses, contributing to energy-efficient designs. The device is compliant with the AEC-Q101 automotive standard, ensuring high reliability in automotive and industrial environments.
The typical voltage temperature coefficient is 3.8 mV/K, providing predictable performance over the operating temperature range from -55°C to 150°C. Its rugged surface mount design with side-wettable flanks supports automated assembly and high yield in production.
This Zener Diode is suitable for industrial electronics, automotive systems, power supply protection, and voltage regulation applications in manufacturing, commercial electronics, and laboratory instrumentation.
Single diode configuration suitable for low bias and portable applications. Compact surface mount DFN1006BD-2 package measuring 1 mm by 0.47 mm. Nominal Zener voltage: 9.1 V ±5% tolerance. Maximum power dissipation: 365 mW.
Test current: 50 μA for low power operation. Compliant with automotive AEC-Q101 reliability standard. Maximum reverse leakage current: 100 nA. Voltage temperature coefficient: 3.8 mV/K. Operating temperature range: -55°C to +150°C.
2-pin configuration for easy PCB mounting and integration. Choose Nexperia BZX8850S-C9V1YL for dependable, high-precision voltage regulation in compact electronic assemblies. Explore more semiconductor and discrete electronic components in the EnvMart catalog to find the best fit for your industrial and laboratory needs.
