Molex Vertical Surface PCB Socket 3-Contact 1 Row 1.25 mm Pitch Tin 502382-0370

The Molex 502382-0370 is a vertical surface mount PCB socket designed for electronic assembly applications requiring reliable wire-to-board connections. This connector features 3 contacts arranged in a single row with a 1.25 mm pitch, optimized for compact PCB layouts where space efficiency is required.

Constructed with a high temperature thermoplastic housing in beige, this socket ensures excellent heat resistance with an operating temperature range from -40°C to 105°C. The copper alloy contacts are plated with tin, enhancing corrosion resistance and electrical conductivity. It supports a voltage rating of 50V AC/DC and a current rating of 1 amp, making it suitable for low power electronic circuits.

Its vertical orientation and surface mount technology facilitate easy PCB assembly and strong mechanical stability. The stacking height of 7.8 mm preserves compactness while allowing secure mating with compatible connectors. Male contact gender is used for connection interfaces in wire-to-board systems.

Designed under Molex's 502382 series, this socket complies with UL E29179 certification, delivering industrial-grade reliability and safety for demanding electronics manufacturing environments including consumer electronics, industrial control systems, and small appliances.

The socket features a vertical orientation to suit surface mount PCB assemblies. It supports a current rating of 1 amp and voltage rating of 50 volts AC/DC. Contacts are made of copper alloy with tin plating for reliable conductivity.

The housing utilizes beige high temperature thermoplastic for durability. Operating temperature ranges from -40 to 105 degrees Celsius for wide environmental tolerance. The stacking height is 7.8 mm enabling compact PCB designs.

Designed as a wire-to-board connector system with male contact gender. Certified to UL E29179 standards, ensuring quality and safety compliance.

This product is ideal for use in industrial electronics, communication devices, consumer products, and other electrical applications requiring secure and reliable PCB connections. Explore more PCB Sockets and connectors in EnvMart's electronics components section.
