| Country of Origin | India |
|---|---|
| Brand | Nexperia |
| Height | 0.47mm |
| Length | 1mm |
| Model | BZX8850S-C24-QYL |
| Mount Type | Surface |
| Series | BZX8850S |
| Maximum Operating Temperature | 150°C |
| Working voltage range | nominal 1.8 V to 75 V |
| Package Type | DFN1006BD-2 |
| Minimum Operating Temperature | -55°C |
| Pin Count | 2 |
| Number of Elements per Chip | 1 |
| Automotive Standard | AEC-Q101 |
| Maximum Power Dissipation Pd | 365mW |
| Diode Configuration | Single |
| Test Current It | 50μA |
| Maximum Reverse Leakage Current | 50nA |
| Nominal Zener Voltage Vz | 24V |
| Zener Type | Voltage Regulator |
| Maximum Zener Impedance | 250Ω |
| Typical Voltage Temperature Coefficient | 18.4mV/K |
The Nexperia BZX8850S-C24-QYL is a high-quality Zener Diode designed as a voltage regulator with a nominal voltage of 24 V and a maximum power dissipation of 365 mW. This diode features a single element per chip configuration housed in a compact DFN1006BD-2 surface mount package with 2 pins, optimized for modern PCB assembly. The device is particularly suited for low current applications, operating at a test current of 50 μA, making it ideal for battery-powered and portable electronic systems where power efficiency is critical.
Compliant with automotive standard AEC-Q101, this Zener diode ensures high reliability under harsh environmental conditions. It supports an extended operating temperature range from -55°C to 150°C, thus suitable for a wide variety of industrial, automotive, and commercial electronics applications.
This device offers a maximum Zener impedance of 250 Ω and maximum reverse leakage current of 50 nA, ensuring precise voltage regulation with low leakage losses. The ultra-small leadless plastic package with side-wettable flanks enhances solderability and assembly yield on PCB manufacturing lines.
The typical voltage temperature coefficient of 18.4 mV/K guarantees stable performance under varying thermal conditions. The working voltage range spans from a nominal 1.8 V up to 75 V, allowing versatile use in multiple voltage regulator scenarios in electronic circuits.
Nexperia's BZX8850S-C24-QYL is engineered for applications in electronic components manufacturing, power and connectors, semiconductor discrete parts, and particularly for circuits requiring reliable voltage regulation with tight tolerance and compact form factor.
Nominal voltage: 24 V with ±5% tolerance. Maximum power dissipation: 365 mW. Leadless surface mount package: DFN1006BD-2. Pin count: 2. Operating temperature: -55°C to 150°C. Automotive standard AEC-Q101 compliant. Low test current: 50 μA ideal for low power consumption.
Maximum reverse leakage current: 50 nA. Typical voltage temperature coefficient: 18.4 mV/K. Working voltage range from 1.8 V to 75 V. Explore more about Nexperia semiconductor components and voltage regulators on EnvMart for your industrial, automotive, and electronics manufacturing projects.
