STMicroelectronics Operational Amplifier 560 MHz 8-Pin 36V MiniSO8 TSB612IYST
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.1mm |
| Length | 3.2mm |
| Model | TSB612IYST |
| Width | 3.1mm |
| Mount Type | Surface |
| Series | TSB612 |
| Maximum Operating Temperature | 125°C |
| Package Type | MiniSO8 |
| Minimum Operating Temperature | -40°C |
| Number Of Channels | 2 |
| Standards/Approvals | RoHS |
| Pin Count | 8 |
| Automotive Standard | AEC-Q100, AEC-Q3 |
| Maximum Supply Voltage | 36V |
| Minimum Supply Voltage | 2.7V |
| GBP - Gain Bandwidth Product | 560MHz |
| Input Bias Current | 15 nA |
| Vos - Input Offset Voltage | 1 mV |
| Slew Rate | 0.2V/μs |
| Input Offset Current | 10 nA |
Key Features
- Provides rail-to-rail output and low offset voltage of 1 mV to ensure precise signal amplification.
- Designed for low power consumption, with less than 125 μA per amplifier at 36 V supply voltage.
- Supports wide supply voltage range from 2.7 V to 36 V suitable for various applications.
- Features low input bias current of 15 nA and low input offset current of 10 nA for stable operation.
- Operates over a temperature range from -40°C to 125°C, meeting automotive standards AEC-Q100 and AEC-Q3.
- Compact dimensions (3.2 mm length, 3.1 mm width, 1.1 mm height) minimize board space for cost-effective PCB designs.
- Suitable for industrial, automotive, communications, and instrumentation applications requiring high-speed and low-power operational amplifiers.
Product Description
STMicroelectronics TSB612IYST Operational Amplifier is a highly reliable semiconductor device designed for low offset voltage and low power consumption while providing a 560 MHz gain bandwidth product. Packaged in a surface-mount 8-pin MiniSO8 format, it supports dual channels and operates comfortably across a wide supply voltage range from 2.7 V to 36 V.
This operational amplifier is particularly well-suited for applications in industrial control systems, automotive electronics, manufacturing instrumentation, and communications where space-saving and efficiency are crucial.
The device adheres to automotive standards AEC-Q100 and AEC-Q3, ensuring performance under stringent operating conditions, including temperatures ranging from -40°C to 125°C. Low input bias and offset currents contribute to signal accuracy and stability.
Its rail-to-rail output capability and unity gain stability make it ideal for precision analogue signal processing tasks. The compact dimensions of 3.2 mm x 3.1 mm x 1.1 mm enable integration into densely populated PCBs, helping reduce overall system costs.
Provides rail-to-rail output and low offset voltage of 1 mV to ensure precise signal amplification. Designed for low power consumption, with less than 125 μA per amplifier at 36 V supply voltage. Supports wide supply voltage range from 2.7 V to 36 V suitable for various applications.
Features low input bias current of 15 nA and low input offset current of 10 nA for stable operation. Operates over a temperature range from -40°C to 125°C, meeting automotive standards AEC-Q100 and AEC-Q3. Compact dimensions (3.2 mm length, 3.1 mm width, 1.1 mm height) minimize board space for cost-effective PCB designs.
Suitable for industrial, automotive, communications, and instrumentation applications requiring high-speed and low-power operational amplifiers.
This product is part of the STMicroelectronics TSB612 series of operational amplifiers, trusted for their quality and compliance with RoHS directives, ensuring environmentally responsible manufacturing.
Explore the full range of Operational Amplifiers on EnvMart to find solutions for your electronic design and prototyping needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The gain bandwidth product of this operational amplifier is 560 MHz.
It supports a wide supply voltage range from 2.7 V to 36 V.
The dimensions are 3.2 mm in length, 3.1 mm in width, and 1.1 mm in height.
The input offset voltage is 1 mV, ensuring precise signal amplification.
The maximum operating temperature is 125°C.
It features 2 channels.
The input bias current is 15 nA, contributing to stable operation.
It meets automotive standards AEC-Q100 and AEC-Q3.
It is packaged in a MiniSO8 format.
The input offset current is 10 nA.
The slew rate is 0.2 V/μs.
It complies with RoHS standards, ensuring environmentally responsible manufacturing.
