Panasonic Shielded Power Choke Coil with Metal Composite Core 6.8μH ±20% 6.7A Idc Surface Mount ETQP4M

Panasonic ETQP4M shielded power choke coil with a metal composite core is engineered for robust automotive and industrial applications requiring stable inductance and high reliability.

This power choke coil offers a nominal inductance of 6.8 microhenries with a ±20% tolerance and supports a maximum DC current of 6.7 amperes. Its metal composite core combined with wirewound construction ensures low DC resistance (35.31 milliohms max) and minimal signal losses.

The device features a shielded surface mount design, which provides excellent electromagnetic interference reduction and low audible buzz noise, enhancing performance in sensitive electronic circuits.

It meets rigorous automotive standard AEC-Q200 and RoHS compliance, assuring suitability for demanding environments with operation temperature spanning from -40°C to 150°C, including self-heating scenarios.

Packaging is provided in tape & reel format, facilitating efficient automated assembly. The choke coil measures 6.4 mm in length, and 4.8 mm in both height and depth, making it compact for high-density PCB designs.

Constructed with a moulded body and two pins, it delivers superior vibration resistance and high bias current capabilities due to the ferrous alloy magnetic material used in the core.

Has an inductance of 6.8 microhenries with ±20% tolerance. Supports a maximum DC current of 6.7 amperes. Features a surface mount package style with tape & reel packaging. Constructed with metal composite core and wirewound inductor construction.

Operates reliably over a temperature range of -40°C to 150°C. Complies with automotive standard AEC-Q200 and RoHS directives. Designed for low DC resistance and high heat resistance up to 150°C including self-heating. Shielded construction minimizes electromagnetic interference and audible noise.

High vibration resistance suitable for automotive and strenuous industrial applications. Measures approximately 6.4 mm length, 4.8 mm height, and 4.8 mm depth.

This power choke coil is ideal for automotive, industrial electronics, power management circuits, and other applications requiring low loss, high heat resistance, and electromagnetic noise reduction. Explore more Panasonic electronics components and related Inductors at EnvMart.
