Honeywell Technologies Piezoresistive Pressure Sensor Surface Mount SMT 8 Pin Dual Radial Barbed 3.3-5V 34 SSCMRRN005PDAA3
Specifications
| Country of Origin | India |
|---|---|
| Accuracy | ±0.25 % |
| Brand | Honeywell |
| Maximum Operating Pressure | 34 kPa |
| Height | 13.75mm |
| Length | 10mm |
| Model | SSCMRRN005PDAA3 |
| Sensor Type | Piezoresistive Pressure Sensor |
| Mount Type | Surface |
| Series | SSC |
| Maximum Operating Temperature | 85°C |
| Port Type | Dual Radial Barbed |
| Package Type | SMT |
| Minimum Operating Temperature | -40°C |
| Pin Count | 8 |
| Maximum Supply Voltage | 5V |
| Minimum Supply Voltage | 3.3V |
| Minimum Operating Pressure | 5psi |
| Maximum Overload Pressure | 206kPa |
Key Features
- High accuracy of ±0.25 percent ensures precise pressure measurements.
- Compact surface mount SMT package suitable for automated PCB assembly.
- Supports a maximum overload pressure up to 206 kPa for robust operation.
- Temperature operation range from -40°C to 85°C for versatile industrial applications.
- Minimum operating pressure of 5 psi (approximately 34 kPa) enables low pressure sensing.
- Equipped with an on-board ASIC enabling calibration and temperature compensation.
- Ideal for industrial, automotive, HVAC, and medical equipment requiring reliable pressure sensing.
- Dual radial barbed port facilitates easy pneumatic connection.
Product Description
Honeywell SSCMRRN005PDAA3 is a piezoresistive pressure sensor designed for surface mount technology (SMT) applications with an 8-pin package and dual radial barbed port type. It operates with supply voltages ranging from 3.3 V to 5 V and supports accurate pressure sensing up to a maximum operating pressure of 34 kPa, withstanding maximum overload pressures of 206 kPa.
The sensor features an accuracy of ±0.25%, providing precise and reliable pressure data needed in sensitive measurement environments. It operates over a temperature range of -40°C to 85°C, making it suitable for harsh industrial, laboratory, automotive, HVAC, and medical device applications. The minimal pin count and surface mount design make it ideal for compact PCB layouts.
Additionally, the SSCMRRN005PDAA3 sensor incorporates an on-board Application Specific Integrated Circuit (ASIC) that performs full calibration including temperature compensation for sensor offset, sensitivity, temperature effects, and non-linearity. This design eliminates the need for additional customer calibration, improving system efficiency and reliability.
This device is ideal for systems requiring precise pressure monitoring with low power consumption and high reliability. Its dual radial barbed port allows straightforward pneumatic interface making it adaptable for a range of industrial automation, fluid control systems, HVAC equipment, and medical instrumentation.
High accuracy of ±0.25 percent for precise pressure measurement. Compact surface mount SMT package ideal for automated assembly. Supports wide temperature range from -40°C to 85°C for rugged environments. On-board ASIC ensures full calibration and temperature compensation.
Dual radial barbed port facilitates easy pneumatic connections. Minimum supply voltage of 3.3V and maximum of 5V offers flexible power options. Maximum overload pressure of 206 kPa for robust sensor operation. Minimal pin configuration reduces PCB layout complexity.
Versatile industrial and commercial applications including automotive and medical. Explore more advanced Pressure Sensor ICs and related components at EnvMart for your industrial and laboratory instrumentation needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum operating pressure of this model is 34 kPa.
It has an accuracy of ±0.25%, ensuring precise pressure measurements.
The sensor operates within a temperature range of -40°C to 85°C.
It features a dual radial barbed port for easy pneumatic connections.
This sensor requires a supply voltage between 3.3V and 5V.
The sensor has an 8-pin configuration, suitable for surface mount technology.
The minimum operating pressure is 5 psi, which is approximately 34 kPa.
The height of this model is 13.75 mm.
It is suitable for industrial, automotive, HVAC, and medical equipment requiring reliable pressure sensing.
Yes, it includes an on-board ASIC that performs full calibration and temperature compensation.
The maximum overload pressure is 206 kPa, ensuring robust operation.
The country of origin for this sensor is India.
