Omron E6C2-C Series Incremental Encoder 24V, 6 mm Shaft Diameter, 500 PPR, PNP Open Collector Output E6C2-CWZ5B 500P/R 2M

Omron E6C2-CWZ5B 500P/R 2M is an Incremental Encoder designed to provide accurate rotational position feedback in automation and motion control applications. This encoder features a 6 mm diameter shaft and is capable of outputting 500 pulses per revolution, enabling precise speed and position measurements essential for industrial control systems.

The encoder operates with a PNP open collector output signal, making it compatible with various control circuits. Constructed with a chassis mount and compliant with IEC standards, it offers robust protection rated at IP64, safeguarding against dust ingress and splashing water, making it suitable for demanding industrial environments.

With a maximum supply voltage of 24V and capable of handling speeds up to 6000 rpm, this encoder supports reliable operations within a wide temperature range from -10°C to 70°C, ensuring performance stability across different working conditions.

The device integrates a cable terminal type connection, facilitating easy installation and maintenance. Its compact build, measuring 60 mm in height and 40 mm in depth, allows integration into space-constrained applications.

This encoder finds extensive usage in industrial machinery, manufacturing automation, robotics, and motion control systems where precise feedback is crucial for efficiency and safety. Its high switching frequency of 100 kHz enables fast and accurate signal processing for dynamic control requirements.

Provides high resolution of 500 pulses per revolution for precise position sensing. Operates at a maximum rotational speed of 6000 rpm. Equipped with an IP64-rated chassis mount for dust and splash resistance. Accepts a maximum supply voltage of 24V, suitable for industrial automation.

Operates reliably within temperature range -10°C to 70°C. Features a cable-type terminal for easy electrical connection. Compact dimensions with 60 mm height and 40 mm depth. Built to IEC standards ensuring quality and interoperability.

Supports switching frequency of 100 kHz for fast signal processing. Explore more Omron automation and control gear products on EnvMart for advanced industrial solutions.
