TE Connectivity M.2 NGFF Series Right Angle Edge Connector Female Surface Mount 67 Contacts 0.5 mm Pitch 2 Row 2199230-4
Specifications
| Country of Origin | China |
|---|---|
| Voltage | 50V |
| Brand | TE Connectivity |
| Orientation | Right Angle |
| Current | 500mA |
| Mount Type | Surface |
| Housing Material | High Temperature Thermoplastic |
| Contact Material | Gold |
| Series | M.2 NGFF |
| Termination Type | Solder |
| Maximum Operating Temperature | -40°C |
| Minimum Operating Temperature | -80°C |
| Number of Rows | 2 |
| Pitch | 0.5mm |
| Standards/Approvals | RoHS |
| Contact Plating | Gold |
| Number of Contacts | 67 |
| Contact Gender | Female |
| Connector Gender | Female |
| Card Type | PCI |
Key Features
- This edge connector is female gender with gold plated gold contacts for enhanced conductivity and corrosion resistance.
- It supports a maximum current of 500mA and voltage rating of 50V suitable for low power applications.
- The connector features a high temperature thermoplastic housing ensuring durability under harsh conditions.
- Keying way is included to prevent improper mating and ensure correct installation.
- It is RoHS compliant, supporting environmental and regulatory standards.
- The operating temperature ranges from -80°C minimum to -40°C maximum for reliability in extreme conditions.
- The termination is solder type, designed for surface mount PCB assembly.
- The series is M.2 NGFF, commonly used in PCI card interfaces for compact electronic device connections.
Product Description
TE Connectivity 2199230-4 is a high quality M.2 NGFF Series edge connector engineered for electronics and electrical component applications. This right angle, female connector with surface mount style includes 67 gold plated contacts arranged in 2 rows with a tight 0.5 mm pitch for precise and secure PCB interconnection.
The connector provides a maximum current rating of 500mA and voltage of 50V, ideal for low power electronic circuits common in compact computing and industrial devices. Its housing is made of high temperature thermoplastic material, offering robust mechanical properties and environmental resistance for industrial and laboratory uses.
With a keying way feature, the connector ensures correct alignment and connection integrity, preventing damage from insertion mistakes. The termination type is solder, compatible with surface mounting technology for automated assembly processes improving manufacturing efficiency.
Operating reliably between -80°C to -40°C, this connector meets demanding settings in industrial electronics, instrumentation, HVAC controls, and communications equipment. It complies with RoHS standards demonstrating adherence to environmental safety requirements.
The M.2 NGFF series edge connector is suited for PCI card type applications, providing a compact and secure electrical interface for printed circuit boards. It originates from China and is a new product widely used in electronic engineering and manufacturing sectors.
Female surface mount connector with gold plated contacts for reliability. 67 contacts arranged in 2 rows with 0.5 mm pitch for compact design. Rated for 500mA current and 50V voltage supporting low power electronics. High temperature thermoplastic housing for durability in harsh environments.
Keying way ensures proper connection and prevents damage from mis-mating. Solder termination for compatibility with modern PCB assembly techniques. RoHS compliant meeting environmental and safety standards. Wide operating temperature range for industrial and laboratory conditions.
Explore the range of Edge Connectors at EnvMart to enhance your electronic component assembly with trusted, high-performance TE Connectivity parts.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this edge connector is 500mA.
This edge connector has a voltage rating of 50V, suitable for low power applications.
The housing of this connector is made from high temperature thermoplastic, providing robust mechanical properties and environmental resistance.
The connector features 67 contacts arranged in 2 rows.
The pitch size of the contacts in this model is 0.5 mm.
This connector uses solder termination, designed for surface mount PCB assembly.
The operating temperature range for this edge connector is from -80°C to -40°C.
Yes, this edge connector is RoHS compliant, meeting environmental and regulatory standards.
This connector is designed for PCI card applications, providing a compact electrical interface.
Yes, it includes a keying way feature to ensure correct alignment and prevent improper mating.
The orientation of this edge connector is right angle, allowing for efficient space utilization on PCBs.
This connector is manufactured in China.
