Omron Power Relay 24V DC Coil Voltage 25A Switching Current DPST-NO, DPST-NC Screw DIN Track Mount G7Z-2A2B-20Z-R DC24

Omron G7Z-2A2B-20Z-R DC24 power relay is designed for industrial and electrical automation applications requiring robust, high-current switching. It maintains controlled switching with a 24V DC coil while supporting switching currents up to 25A.

This relay offers a DPST contact configuration with both normally open and normally closed contacts enabling flexible circuit control. The mounting options include screw and DIN track installations allowing straightforward integration into control panels or rail-mounted setups.

The coil consumes 3.7 watts of power and has a coil resistance of 156 ohms, delivering predictable coil drive and stable performance under varied electrical conditions. It can reliably switch AC voltages up to 480V and DC voltages up to 125V, making it ideal for motor control, distribution systems, and renewable energy battery management.

Silver alloy contacts with 400 milliohm contact resistance ensure low-loss conductivity and extended lifecycle under heavy currents. Its operational temperature range of -25°C to 60°C covers most industrial ambient requirements, enhancing dependability.

Compact in size with dimensions 92.2 mm (W) × 62 mm (H) × 45 mm (L), it fits well into limited space architectures. Omron’s adherence to RoHS standards reflects its environmental compliance and safety.

Typical applications include motor control circuits in automation, high-current AC load switching, DC power isolation in battery systems, and control logic interfaces in industrial machinery. The reliable screw terminal connections facilitate secure wiring in demanding electrical environments.

Operates with a DPST contact configuration providing both normally open and normally closed contacts. Mounts via screw or DIN rail for versatile installation options. Coil power consumption is 3.7W with 156Ω coil resistance ensuring reliable operation.

Rated to switch up to 480V AC and 125V DC for diverse high load applications. Durable silver alloy contacts with 400mΩ contact resistance for efficient conduction. Wide operating temperature range from -25°C to 60°C suitable for harsh industrial environments.

Compact dimensions with 92.2mm width, 62mm height, and 45mm length for easy panel integration. Complies with RoHS standards ensuring restricted hazardous substances. Explore more Omron Power Relays and related industrial automation components on EnvMart for reliable performance and robust electrical control solutions.
