STMicroelectronics Through Hole 3-Pin TRIAC 600 V, Gate Trigger 1.3 V BTB08-600CWRG
Specifications
| Country of Origin | China |
|---|---|
| Brand | STMicroelectronics |
| Height | 15.9mm |
| Length | 10.4mm |
| Model | BTB08-600CWRG |
| Mount Type | Through Hole |
| Configuration | Single |
| Maximum Operating Temperature | 150°C |
| Package Type | TO-220 |
| Minimum Operating Temperature | -40°C |
| Pin Count | 3 |
| Rated Average On-State Current Irms | 8A |
| Repetitive Peak Reverse Voltage VDRM | 600V |
| Surge Current Rating | 84A |
| Maximum Gate Trigger Current Igt | 35mA |
| Maximum Holding Current Ih | 35mA |
| Maximum Gate Trigger Voltage Vgt | 1.3V |
| Peak On-State Voltage | 1.55V |
| Repetitive Peak Off-State Current | 1mA |
| Peak Gate Power Dissipation | 1W |
Key Features
- The device supports a rated average on-state current of 8 A.
- It features a surge current rating of 84 A to handle transient overloads.
- The TRIAC is supplied in a TO-220 package designed for easy through-hole mounting.
- Maximum gate trigger current is 35 mA with a trigger voltage of 1.3 V.
- Operating temperature range extends from -40°C to 150°C for robust performance.
- Peak on-state voltage is 1.55 V ensuring efficient conduction.
- Designed with a height of 15.9 mm and length of 10.4 mm to fit compact PCB layouts.
- It has a repetitive peak reverse voltage rating of 600 V for high voltage applications.
Product Description
STMicroelectronics BTB08-600CWRG is a through-hole 3-pin TRIAC designed to switch and control AC power efficiently and reliably. Rated for a maximum repetitive peak reverse voltage of 600 V and a surge current of 84 A, this device supports a rated average on-state current of 8 A, making it suitable for medium-power AC load switching applications.
The TRIAC's gate requires a low trigger current of 35 mA and voltage of 1.3 V, enabling easy interfacing with control circuits. Packaged in the industry-standard TO-220 through-hole format, it provides reliable mechanical stability and thermal dissipation capabilities.
Operating temperature range from -40°C to 150°C ensures stable performance under harsh environmental conditions. Its compact dimensions of 15.9 mm height and 10.4 mm length facilitate compact PCB design layouts.
This TRIAC is widely used in industrial control systems, lighting control, motor speed control, and other power switching applications where precise AC load control is required. The device supports a rated average on-state current of 8 A.
Surge current rating of 84 A for transient overload conditions. TO-220 package suitable for through-hole mounting. Maximum gate trigger current of 35 mA and voltage of 1.3 V for efficient triggering. Temperature operation from -40°C to 150°C.
Peak on-state voltage of 1.55 V reduces power loss during conduction. Compact dimensions help in space-constrained applications. Repetitive peak reverse voltage of 600 V for high voltage capability. Suitable for industrial, commercial, and consumer AC power control uses.
Explore EnvMart's extensive selection of semiconductor components including TRIACs to find the right products for your electronics manufacturing and design needs.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The rated average on-state current for this model is 8 A.
This TRIAC has a maximum repetitive peak reverse voltage rating of 600 V.
The surge current rating is 84 A, allowing it to handle transient overloads effectively.
The dimensions of the TO-220 package are 15.9 mm in height and 10.4 mm in length.
The maximum gate trigger voltage is 1.3 V, and the maximum gate trigger current is 35 mA.
The operating temperature range extends from -40°C to 150°C.
The peak on-state voltage is 1.55 V, which helps reduce power loss during conduction.
This model supports through-hole mounting, making it suitable for various PCB layouts.
This TRIAC is suitable for applications such as industrial control systems, lighting control, and motor speed control.
The maximum holding current for this device is 35 mA.
The package type of this model is TO-220, which provides mechanical stability and thermal dissipation capabilities.
The peak gate power dissipation for this TRIAC is 1 W.
