STMicroelectronics 2 Flip Flop IC, 14-Pin SO, Surface Mount, 3V-20V Supply, 24MHz Clock Frequency, D Flip-Flop HCF4013YM013TR
Specifications
| Country of Origin | India |
|---|---|
| Brand | STMicroelectronics |
| Height | 1.65mm |
| Length | 8.75mm |
| Model | HCF4013YM013TR |
| Mount Type | Surface |
| Series | HCF4013YM013TR |
| Input Type | Single Ended |
| Maximum Operating Temperature | 125°C |
| Package Type | SO |
| Minimum Operating Temperature | -40°C |
| Polarity | Inverting, Non-Inverting |
| Trigger Type | Positive Edge |
| Pin Count | 14 |
| Number of Elements per Chip | 2 |
| Automotive Standard | AEC-Q100 |
| Maximum Supply Voltage | 20V |
| Minimum Supply Voltage | 3V |
| Maximum Propagation Delay Time @ CL | 90ns |
| Clock frequency | 24MHz |
| Flip-Flop Type | D Flip-Flop |
| CDM | 1 kV |
| HBM | 2 kV |
| MM | 200 V |
Key Features
- Features two independent D flip-flops with set, reset, and clock inputs.
- Supports clock frequencies up to 24MHz for medium speed operation.
- Operates over a temperature range from -40°C to 125°C.
- Has a maximum propagation delay time of 90ns at load capacitance.
- Input type is single-ended with inverting and non-inverting polarity options.
- Designed with metal oxide semiconductor technology for reliable performance.
- Supports positive edge triggering for clock input.
- Complies with AEC-Q100 automotive standard for quality assurance.
Product Description
STMicroelectronics HCF4013YM013TR is a monolithic integrated circuit fabricated using metal oxide semiconductor technology. It includes two identical and independent D-type flip-flops, each featuring separate data, set, reset, and clock inputs along with Q and Q' outputs. The device is housed in a 14-pin SO surface-mount package, optimizing space for modern electronic designs.
This dual flip-flop IC can be used in various applications such as shift registers, counters, and toggle circuits by connecting output Q to the data input. The logic state at the D input is transferred to the outputs on the positive edge of the clock pulse. The set and reset functions operate independently of the clock, allowing asynchronous control.
The device supports a clock frequency of up to 24MHz, with a maximum propagation delay of 90ns at typical load capacitance. Its operating temperature range from -40°C to +125°C and supply voltage range from 3V to 20V make it suitable for a wide range of industrial, automotive, and consumer electronics environments.
Thanks to standardized symmetrical output characteristics and low quiescent current, this IC ensures reliable static operation and energy efficiency. It meets the AEC-Q100 automotive standard, underlining its quality and durability for automotive-grade applications.
The HCF4013YM013TR is ESD protected with Human Body Model rating of 2kV, Machine Model 200V, and Charge Device Model 1kV, safeguarding it against electrostatic discharge damage. Two independent D flip-flops with asynchronous set and reset inputs.
Positive edge clock triggering for precise data transfer. Wide supply voltage range suitable for varied applications. Robust operating temperature tolerance from -40°C to 125°C. Compact 14-pin SO package ideal for surface mount PCB design.
Excellent ESD protection and low quiescent current enhance durability. Applications include counters, toggles, and shift registers. This flip-flop IC is well suited for electronics manufacturing, automotive systems, industrial controllers, and embedded systems requiring reliable bi-stable storage elements.
Explore more semiconductor components and IC solutions at EnvMart, your trusted source for industrial and electronics components.
Explore more products in our Flip Flop ICs category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum clock frequency supported by this model is 24MHz, allowing for medium speed operation.
This unit operates over a temperature range from -40°C to +125°C, making it suitable for various environments.
The maximum propagation delay time is 90ns at typical load capacitance, ensuring quick data transfer.
It features a single-ended input type with both inverting and non-inverting polarity options.
The HCF4013YM013TR contains two independent D flip-flops, each with separate data, set, reset, and clock inputs.
The package dimensions are 8.75mm in length and 1.65mm in height, optimized for surface mount applications.
It complies with the AEC-Q100 automotive standard, ensuring quality assurance for automotive applications.
The supply voltage range is from 3V to 20V, accommodating a variety of applications.
This model uses positive edge triggering for the clock input, allowing precise data transfer.
It can be used in various applications such as shift registers, counters, and toggle circuits.
It is ESD protected with a Human Body Model rating of 2kV, Machine Model 200V, and Charge Device Model 1kV.
This model is designed for surface mounting, suitable for modern PCB designs.
