Molex Right Angle Surface Mount Female USB Type B Connector USB 2.0 30V 1.8A 47346-1001

Molex 47346-1001 is a right angle, surface mount female USB Type B connector designed to meet USB 2.0 specifications. It supports a current rating of 1.8A and operates within a voltage of 30V, providing efficient and reliable data and power connections in electronic applications.

This connector features a robust copper alloy contact material that ensures enhanced electrical conductivity and durability under various operating conditions. The right angle orientation makes it ideal for applications requiring compact PCB layouts.

The surface mount design facilitates easy and consistent PCB assembly, using solder termination for a secure and reliable connection. It is suitable for operating temperatures ranging from -30°C to 85°C, allowing use in a wide range of industrial and commercial electronic environments.

As a single port USB Type B female connector, it fits seamlessly into electronic devices where USB 2.0 connections are required. This part is part of Molex's 4734 series and is manufactured in China, ensuring quality compliance and industry standards.

Designed for USB 2.0 specification ensuring backward compatibility. Surface mount type allows easy PCB assembly. Right angle orientation for compact design applications. Rated for 1.8A current and 30V operating voltage. Durable copper alloy contact material for enhanced conductivity.

Operating temperature range from -30°C to 85°C. Solder termination type for secure soldering to PCB. Compact single port connector suitable for various electronics.

This USB connector is widely used in electronic components manufacturing, power distribution systems, and devices requiring USB interface connectivity. It supports integration in industrial, laboratory, consumer electronics, and commercial equipment manufacturing environments.
