Panasonic Black Tactile Switch Push Plate SPST 20mA 250V AC Surface Mount 2.5mm EVPBT5A4A000
Specifications
| Country of Origin | Malaysia |
|---|---|
| Brand | Panasonic |
| Height | 1.8mm |
| Model | EVPBT5A4A000 |
| Mount Type | Surface |
| Series | EVPBT |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | SPST |
| Switch Configuration | SPST |
| Minimum Operating Temperature | -40°C |
| Terminal type | Straight |
| Standards/Approvals | RoHS |
| Switch Operation | Push-On |
| Actuator Colour | Black |
| Actuator Length | 2.5mm |
| Actuator Style | Push Plate |
| Switch Contact Current | 20mA |
| Operating Force | 1.6N |
| Mechanical Life | 1000000Cycles |
| Contact AC Voltage | 250V ac |
Key Features
- The switch operates at 250 V AC contact voltage with a contact current rating of 20mA.
- It provides a mechanical life of 1,000,000 cycles ensuring long-term reliability.
- The compact 2.5 mm actuator length and 1.8 mm height enable low profile applications.
- Operating temperature range spans from -40°C to +85°C for versatile environmental usage.
- The push plate actuator style offers easy and tactile feedback for user interfaces.
- Surface mount design supports modern PCB assembly techniques.
- Complies with RoHS for environmental and safety standards.
- Manufactured in Malaysia with Panasonic EVPBT series quality assurance.
Product Description
Panasonic EVPBT5A4A000 is a black tactile switch push plate designed for surface mount applications in electronic user interfaces. This SPST switch operates at 250 V AC and 20mA contact current, making it ideal for precise on/off control in various electrical and automation devices.
The actuator length of 2.5 mm combined with low-profile height of 1.8 mm allows compact integration into circuit boards while delivering reliable tactile feedback with an operating force of 1.6N. Tested for mechanical durability, it withstands up to 1,000,000 cycles.
Engineered for reliability in harsh environments, this tactile switch functions within a temperature range of -40°C to 85°C. Its compliant RoHS standard ensures environmentally conscious manufacturing.
Suitable for industrial, laboratory, electronic instrumentation, automation, and general manufacturing use, the surface mount tactile switch enhances product usability and longevity.
The switch operates at a 250 V AC contact voltage with a 20mA current rating. Mechanical lifespan of 1,000,000 operational cycles. Compact black push plate actuator with 2.5 mm length and 1.8 mm height. Operating force requirement of 1.6 Newtons for actuation.
Wide temperature tolerance from -40°C to 85°C for versatile application environments. Surface mount design compatible with standard PCB layouts. Complies with RoHS directives ensuring environmental compliance. Manufactured in Malaysia to Panasonic quality specifications and EVPBT series standards.
This Panasonic tactile switch series offers reliable switching for electronic control panels, instrumentation, consumer electronics, and automation equipment. It is designed to enhance user interface performance with robust tactile feedback over extended product life cycles.
Explore more Panasonic switches and Tactile Switch options in EnvMart’s extensive Electronics & Electricals catalog for precision and quality components.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switch operates at a contact voltage of 250 V AC and has a contact current rating of 20mA.
It has a mechanical life rated for up to 1,000,000 cycles, ensuring long-term reliability.
The actuator length is 2.5 mm and the height is 1.8 mm, allowing for compact integration into circuit boards.
It functions within a temperature range of -40°C to +85°C, making it suitable for various environmental conditions.
This model features an SPST (Single Pole Single Throw) switch configuration.
The switch is actuated using a push plate style, providing tactile feedback for user interfaces.
The operating force required for actuation is 1.6 Newtons.
This unit is designed for surface mounting, compatible with standard PCB layouts.
Yes, it complies with RoHS standards for environmental and safety requirements.
It is manufactured in Malaysia, adhering to Panasonic's quality specifications.
This tactile switch is suitable for use in industrial, laboratory, electronic instrumentation, automation, and general manufacturing applications.
The switch features straight terminals for easy connection.
