Keithley Data Acquisition Coupler Control Module 40-Channel 300V 2A for 2700, 2701, 2750 Series 7705

Keithley 7705 Data Acquisition Coupler Control Module is a high-performance accessory designed for use with Keithley 2700, 2701, and 2750 series systems. This 40-channel single-pole control module allows independent switching of power and loads, making it highly suitable for precise data acquisition and test measurement applications.

Each of the 40 channels is capable of controlling power to the Device Under Test (DUT) and various switching loads, enabling direct management of indicators, relays, and other devices. The module features robust relay closures stored in onboard memory, ensuring reliable operation throughout testing cycles.

Connectivity is simplified with two 50-pin female D-sub connectors that facilitate quick and secure hook-up and teardown, enhancing workflow efficiency in laboratory and industrial environments. The 7705 module supports a voltage capacity of 300 V and a current capacity of 2 A, providing substantial power handling for diverse applications.

This control module is compatible with popular Keithley systems including the 2700 (760-0354, 760-0357), 2701 (760-0351), and 2750 (760-0360) series models, serving as an integral part of test setups requiring reliable multiplexing and switching solutions.

The package supplied includes mating connectors (2) with solder cup (Model 7788), facilitating immediate integration into test systems. The Keithley 7705 module finds applications across industrial automation, laboratory testing, electronics manufacturing, and quality control environments.

The module offers 40-channel independent switching for power control and load switching. Designed to control power to Devices Under Test (DUT) and switching loads effectively. Features two 50-pin female D-sub connectors for simple hook-up and quick teardown.

Supports direct control of devices such as indicators and relays. Relay closures are stored in onboard memory for efficient operation. Compatible with Keithley systems 2700, 2701, and 2750 series control modules. Offers a capacity of 300 volts and 2 amperes per channel.

Includes mating connectors (two) with solder cup (Model 7788) supplied. For detailed data acquisition and control module needs, explore the comprehensive Keithley offerings available at EnvMart.
