C & K Rotary Coded DIP Switch Surface Mount Flush Actuator TDA10H0SB1R
Specifications
| Country of Origin | India |
|---|---|
| Brand | C & K |
| Model | TDA10H0SB1R |
| Mount Type | Surface Mount |
| Actuator Type | Flush |
| Switch Contact Rating | 25 mA @ 24 V dc |
| Electrical Life | 1000 cycles minimum |
Key Features
- The switch features ultra-miniature half pitch design suited for space-constrained circuits.
- Bifurcated contacts provide increased electrical reliability and durability.
- Rated for 25 mA at 24 V DC switching capability.
- Durable electrical life of at least 1000 operation cycles.
- Surface mount type enhances ease of PCB assembly and manufacturing efficiency.
- The flush actuator ensures a low profile for streamlined device integration.
- Applications include handheld devices, computers, test equipment, and instrumentation.
Product Description
C & K TDA10H0SB1R Rotary Coded DIP Switch is an ultra-miniature surface mount Rotary Coded DIP Switch featuring a flush actuator designed for high reliability and compact electronic assemblies.
This product belongs to the industry-standard TDA series, characterized by a half pitch form factor that allows for dense PCB configurations without compromising switching performance.
The switch incorporates bifurcated contacts to enhance electrical reliability over repeated cycles, supporting a contact rating of 25 mA at 24 V DC. Its robust design ensures a minimum electrical life of 1000 cycles, suitable for a broad range of industrial and commercial applications.
Designed to mount on the surface of printed circuit boards, the device improves manufacturing efficiency with reel packaging ready for automated insertion. The flush actuator provides a slim profile, making it ideal for handheld devices and compact instrumentation.
Typical use cases include deployment in handheld electronic devices, computing equipment, test apparatus, and various precision instrumentation where reliable rotary coded switching is critical.
The switch features ultra-miniature half pitch design suited for space-constrained circuits. Bifurcated contacts provide increased electrical reliability and durability. Rated for 25 mA at 24 V DC switching capability. Durable electrical life of at least 1000 operation cycles.
Surface mount type enhances ease of PCB assembly and manufacturing efficiency. The flush actuator ensures a low profile for streamlined device integration. Applications include handheld devices, computers, test equipment, and instrumentation.
Explore more switches and related components in the Electronics & Electricals category at EnvMart for quality and reliability.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The switch has a contact rating of 25 mA at 24 V DC.
It has a durable electrical life of at least 1000 operation cycles.
The TDA10H0SB1R is designed for surface mount installation on printed circuit boards.
This unit features a flush actuator, providing a low profile for device integration.
It is suitable for handheld devices, computers, test equipment, and instrumentation.
The switch features an ultra-miniature half pitch design, which is suited for space-constrained circuits.
The switch incorporates bifurcated contacts, which provide increased electrical reliability and durability.
The country of origin for this switch is India.
It comes in reel packaging, enhancing manufacturing efficiency for automated insertion.
The minimum electrical life specified is 1000 cycles.
It is suited for space-constrained circuits due to its ultra-miniature design.
The primary feature is its ultra-miniature design, making it ideal for compact electronic assemblies.
