C & K Extended Rotary Coded DIP Switch Surface Mount SDA08H1SBD

C & K SDA08H1SBD Extended Rotary Coded DIP Switch Surface Mount is a high-quality low profile SPST switch designed for surface mount technology applications. It features an extended actuator, providing easy handling for setting configurations in devices.

This rotary coded DIP switch is part of the renowned SDA series by C & K, recognized for offering reliable electrical performance in telecommunication, computer electronics, test and measurement equipment, security systems, and instrumentation devices. Its surface mount design ensures straightforward integration into modern PCB layouts, reducing manual assembly time.

The switch contact rating supports 100 mA at 5 V dc or 25 mA at 24 V dc, suitable for low voltage control signaling. With an electrical life of at least 1000 cycles, it guarantees dependable operation over extended periods.

The extended actuator type allows for tactile feedback and ease of user setting while maintaining a compact switch footprint. This switch is supplied in a tube format to optimize production efficiency and insertion into automated manufacturing lines.

Applications for this component include telecom equipment, computer peripherals, industrial test instruments, security alarm panels, and various instrumentation modules requiring coded rotary selection inputs.

The switch features an extended actuator type for ease of operation. Designed for surface mount installation, simplifying PCB assembly. Switch contact rating is 100 mA at 5 V dc or 25 mA at 24 V dc ensuring low power signal switching.

Electrical life rating of a minimum of 1000 cycles ensures durability. Part of the SDA series, known for low profile SPST switches suitable for various electronics.

EnvMart offers this C & K Rotary Coded DIP Switch suitable for professional industrial, commercial, laboratory, and manufacturing environments requiring precise switching and configurability.
