STMicroelectronics Brushed DC Motor Driver IC Half Bridge 30A 40V 30-Pin MultiPowerSO VNH3SP30TR-E

STMicroelectronics VNH3SP30TR-E Brushed DC Motor Driver IC is engineered for efficient and reliable control of brushed DC motors in automotive and industrial applications. It features a half bridge configuration capable of delivering a maximum output current of 30 amperes.

The device supports a wide operating voltage range from 5.5 volts to 36 volts, allowing compatibility with various power supply specifications. Protection features include undervoltage and overvoltage shutdown mechanisms, thermal shutdown to prevent overheating, and overvoltage clamps enhancing device safety during transient events.

Its MultiPowerSO 30-pin surface mount package ensures compact integration into printed circuit boards while simplifying assembly. The typical switching frequency of 10 kHz enables effective pulse width modulation for motor speed regulation.

The component is designed to operate reliably in extreme temperatures from -40°C to 150°C, meeting stringent automotive quality standards including AEC-Q100 certification. Additional functionality consists of a linear current limiter and cross-conduction prevention that safeguard the motor drive circuitry.

Supports output current up to 30 amps for robust motor control. Operates at supply voltages from 5.5V up to 36V. Features thermal shutdown and overvoltage clamps for protection. Designed with 30 pins in a MultiPowerSO package for surface mounting.

Functions with a typical switching frequency of 10 kHz for PWM motor control. Robust operation over a temperature range from -40°C to 150°C. Includes linear current limiting and cross-conduction protection. Very low standby power consumption enhances efficiency.

Complies with automotive standard AEC-Q100 for reliability. Compact dimensions of 17.2 mm by 16 mm by 2.25 mm.

This Motor Driver IC is ideal for applications in automotive control systems, industrial machinery, and other environments requiring high current motor driving capability with advanced protection features. Its performance and reliability suit it for harsh operating conditions and extended temperature ranges.
