ROHM Brushed DC Motor Driver IC Half Bridge 18 V 2 A 7-Pin HRP BD6222HFP-TR

Free Delivery in India | Lowest Global Shipping Charges

ROHM Brushed DC Motor Driver IC Half Bridge 18 V 2 A 7-Pin HRP BD6222HFP-TR

Name: ROHM Brushed DC Motor Driver IC Half Bridge 18 V 2 A 7-Pin HRP BD6222HFP-TR
Brand: ROHM
SKU: 214038
Price: 3.48 USD
Availability: InStock



Category Motor Driver IC Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	1.91mm
Length	9.4mm
Model	BD6222HFP-TR
Width	8mm
Motor Type	Brushed DC Motor
Mount Type	Surface
Series	BD6222HPF
Configuration	Half Bridge
Output Current	2A
Maximum Operating Temperature	85°C
Package Type	HRP
Minimum Operating Temperature	-40°C
Pin Count	7
Maximum Collector Emitter Voltage Vceo	18V
Maximum Supply Voltage	15V
Minimum Supply Voltage	6V
Supply Current	2.5mA
Maximum IGBT Collector Current	2A
Typical Switching Frequency	100kHz
Inverter Power Rating	1.6W

Key Features

Designed for reliable control of brushed DC motors in electronic applications.
Operates with a supply voltage range from 6 V to 15 V for versatile power input.
Offers a compact 7-pin HRP surface-mount package ideal for PCB integration.
Supports maximum collector emitter voltage of 18 V and maximum output current of 2 A.
Features a typical switching frequency of 100 kHz for efficient motor control.
Operates within a wide temperature range from -40°C to 85°C ensuring stability under harsh conditions.
Consumes low supply current of 2.5 mA contributing to energy-efficient designs.
Package dimensions are 9.4 mm length, 8 mm width, and 1.91 mm height for compact mounting.

Product Description

ROHM BD6222HFP-TR is a Brushed DC Motor Driver IC designed for industrial and electronic applications requiring precise motor control. This half bridge configuration IC supports a maximum output current of 2 A and can handle collector emitter voltages up to 18 V, enabling robust performance for brush motor management.

It operates efficiently across a wide supply voltage range of 6 V to 15 V and incorporates a typical switching frequency of 100 kHz, facilitating responsive and reliable motor speed regulation.

The device package is a compact 7-pin HRP surface-mount type, measuring 9.4 mm in length, 8 mm in width, and 1.91 mm in height, suitable for modern PCB layouts with spatial constraints.

This motor driver IC withstands operating temperatures from -40°C to 85°C, making it suitable for various industrial environments including automotive electronics, factory automation systems, consumer electronics, and robotics.

Additional technical characteristics include a supply current of just 2.5 mA, promoting efficient power usage in embedded controls. Although this IC has no specific automotive standard certifications and approvals, it is nonetheless optimized for durable motor control applications.

Typical use cases for the ROHM BD6222HFP-TR encompass driving brushed DC motors in HVAC systems, laboratory instruments, manufacturing automation, and power management in electronic devices.

Designed for reliable control of brushed DC motors in electronic applications. Operates with a supply voltage range from 6 V to 15 V for versatile power input. Offers a compact 7-pin HRP surface-mount package ideal for PCB integration.

Supports maximum collector emitter voltage of 18 V and maximum output current of 2 A. Features a typical switching frequency of 100 kHz for efficient motor control. Operates within a wide temperature range from -40°C to 85°C ensuring stability under harsh conditions.

Consumes low supply current of 2.5 mA contributing to energy-efficient designs. Package dimensions are 9.4 mm length, 8 mm width, and 1.91 mm height for compact mounting. Explore the full range of Motor Driver ICs at EnvMart for advanced electronic component solutions.
