ROHM Brushed DC Motor Driver IC Half Bridge 18 V 2 A 7-Pin HRP BD6222HFP-TR

Free Delivery in India | Lowest Global Shipping Charges

ROHM Brushed DC Motor Driver IC Half Bridge 18 V 2 A 7-Pin HRP BD6222HFP-TR

Name: ROHM Brushed DC Motor Driver IC Half Bridge 18 V 2 A 7-Pin HRP BD6222HFP-TR
Brand: ROHM
SKU: 214039
Price: 3.48 USD
Availability: InStock



Category Motor Driver IC Brand ROHM Condition New

Specifications

Country of Origin	India
Brand	ROHM
Height	1.91mm
Length	9.4mm
Model	BD6222HFP-TR
Width	8mm
Motor Type	Brushed DC Motor
Mount Type	Surface
Series	BD6222HPF
Configuration	Half Bridge
Output Current	2A
Maximum Operating Temperature	85°C
Package Type	HRP
Minimum Operating Temperature	-40°C
Pin Count	7
Maximum Collector Emitter Voltage Vceo	18V
Maximum Supply Voltage	15V
Minimum Supply Voltage	6V
Supply Current	2.5mA
Maximum IGBT Collector Current	2A
Typical Switching Frequency	100kHz
Inverter Power Rating	1.6W

Key Features

Supports brushed DC motors with half bridge configuration.
Maximum collector emitter voltage of 18 V ensuring robust output handling.
Rated output current of 2 A suitable for medium power applications.
Operates within a temperature range from -40°C to 85°C for versatile environments.
Compact surface mount HRP package with 7 pins for easy PCB integration.
Typical switching frequency of 100 kHz for efficient motor control.
Low supply current consumption of 2.5 mA reduces overall power usage.
Minimum supply voltage of 6 V and maximum of 15 V provides operational flexibility.

Product Description

ROHM BD6222HFP-TR is a high-performance Brushed DC Motor Driver IC designed specifically for efficient control of brushed DC motors using a half bridge configuration. This device supports a maximum collector emitter voltage of 18 V and an output current rating of 2 A, making it suitable for a wide range of industrial and commercial motor control applications.

The IC is housed in a compact HRP surface mount package with 7 pins, allowing for easy and space-saving integration onto printed circuit boards. Operating across a wide temperature range from -40°C to 85°C, it is adaptable for demanding environments in industrial, manufacturing, and automation sectors.

Its typical switching frequency of 100 kHz enables smooth and efficient motor operation and speed control. The device also has a low supply current of 2.5 mA, minimizing power consumption and heat generation in circuit designs.

This motor driver IC can operate with supply voltages ranging from 6 V up to 15 V, providing operational flexibility for diverse power supply setups. The physical dimensions of the package are approximately 9.4 mm in length, 8 mm in width, and 1.91 mm in height, making it suitable for compact electronics applications.

While the product does not meet automotive certifications or standards, it is well-suited for use in industrial motor control, robotics, HVAC systems, appliance controls, and other automation applications.

Supports brushed DC motors with half bridge configuration. Maximum collector emitter voltage of 18 V ensuring robust output handling. Rated output current of 2 A suitable for medium power applications. Capable of operating between -40°C and 85°C ambient temperatures.

Compact HRP surface mount package with 7 pins for PCB mounting. Typical switching frequency of 100 kHz for efficient motor control. Low supply current consumption of 2.5 mA for energy efficiency. Supply voltage range of 6 V to 15 V for flexible power supply.

Package dimensions approximately 9.4 mm x 8 mm x 1.91 mm. Ideal for industrial, robotics, HVAC, and commercial motor driver applications.

Explore the Electronics & Electricals category at EnvMart for more advanced Motor Driver ICs including models from ROHM and other trusted brands to enhance your projects and machinery controls.
