STMicroelectronics 1-Element Bi-Directional TVS Diode 5 kW, 2-Pin R-6 BZW50-27B

STMicroelectronics BZW50-27B is a single-element, bi-directional Transient Voltage Suppressor (TVS) diode designed for high power transient voltage protection in electronic circuits. This diode delivers a peak pulse power dissipation of 5 kW, ensuring excellent protection against voltage spikes and surges that could potentially damage sensitive semiconductor devices.

Encapsulated in a compact 2-pin through-hole R-6 package, this diode offers ease of mounting and integration on printed circuit boards typical in industrial, laboratory, and electronic manufacturing settings. Its bi-directional construction provides symmetrical protection in both forward and reverse voltage directions, making it suitable for AC and DC applications where transient voltages can occur.

The device has a minimum breakdown voltage (Vbr) of 30 V and a maximum reverse standoff voltage (Vwm) of 27 V. It clamps voltage transients at 62 V, safely limiting voltage excursions. The diode can handle a maximum peak pulse current (Ippm) of 968 A, providing robust defense against large transient currents.

Operational temperature range extends from -65°C to +175°C, allowing use in harsh environmental conditions including automotive electronics, power supplies, and industrial controls. The maximum reverse leakage current is limited to 5 μA, enhancing efficiency by minimizing leakage losses during normal operation.

This product does not carry specific automotive or industry certifications but is widely used across electronic component applications to improve system reliability and reduce downtime caused by voltage transient damage.

The BZW50 series axial TVS diode ensures consistent electrical transient suppression in various environments. Ideal for circuit protection in industrial equipment, power distribution, and electronic instrumentation. Through-hole mounting facilitates robust mechanical and electrical connection.

Compact footprint and lightweight design optimize PCB space utilization. Reliable over a broad temperature range, suitable for rigorous operating conditions. Designed for quick response to voltage surges to protect sensitive downstream components.

Minimal reverse leakage maintains circuit efficiency during steady state. Single element chip construction guarantees predictable and stable voltage clamping.

Choose the STMicroelectronics BZW50-27B TVS diode for dependable transient voltage suppression compatible with high-power and sensitive electronic applications. Explore more in the TVS Diode category at EnvMart for advanced solutions to protect your electronic investments.
