Wurth Elektronik WR-TBL Series 5-Contact 3.81 mm Pitch 1 Row Vertical Pluggable Terminal Block 691348300005
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1.6kV ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 8A |
| Length | 19.9mm |
| Depth | 18.3mm |
| Width | 11.1mm |
| Housing Material | Polyamide 66 |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Number of Contacts | 5 |
| Connector Gender | Male |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 2.08mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
Key Features
- Supports a current rating of 8A suitable for moderate electrical loads.
- Constructed with polyamide 66 housing ensuring durability and heat resistance.
- Features brass contacts with tin plating for reliable conductivity.
- Wire connection via screw method supports wire sizes from 0.05 mm² to 2.08 mm².
- Operates at a working voltage of up to 300V AC with 1.6 kV ac withstanding voltage.
- Designed for an operating temperature range from -40°C to +115°C enabling broad industrial applications.
- Suitable for industrial, manufacturing, and electronic assembly use cases requiring robust terminal connections.
Product Description
Wurth Elektronik 691348300005 is a high-quality WR-TBL Series pluggable terminal block designed for reliable vertical PCB connections with 5 contact points and a 3.81 mm pitch. It features a robust polyamide 66 housing combined with brass contacts using tin plating, providing excellent electrical conduction and mechanical resilience.
Engineered to handle up to 8A current at a working voltage of 300V AC, this terminal block supports a wide wire size range from 0.05 mm² (AWG 30) to 2.08 mm² (AWG 14). The screw-type wire connection ensures secure and stable contact, suitable for intensive industrial environments.
The product dimensions of length 19.9 mm, width 11.1 mm, and depth 18.3 mm allow for space-efficient integration on printed circuit boards. With an operating temperature range spanning from -40°C to +115°C and a high 1.6 kV AC voltage withstand rating, this component offers excellent durability and safety compliance for demanding applications.
This pluggable terminal block is ideal for electronic manufacturing, power distribution terminals, industrial automation, and other professional electrical engineering projects requiring secure, high-quality PCB terminations.
Supports a current rating of 8A suitable for moderate electrical loads. Constructed with polyamide 66 housing ensuring durability and heat resistance. Features brass contacts with tin plating for reliable conductivity. Wire connection via screw method supports wire sizes from 0.05 mm² to 2.08 mm².
Operates at a working voltage of up to 300V AC with 1.6 kV AC withstanding capability. Compact dimensions facilitate integration into diverse PCB layouts. Wide operating temperature range from -40°C to +115°C. Complies with RoHS and lead-free standards ensuring environmental safety.
Discover more electronic components and connectors at EnvMart to meet your design and manufacturing needs.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 8A, making it suitable for moderate electrical loads.
This terminal block operates at a working voltage of up to 300V AC, with a withstand voltage of 1.6 kV AC.
The wire connection method supports wire sizes ranging from 0.05 mm² to 2.08 mm² (30 AWG to 14 AWG).
The housing is constructed from polyamide 66, which ensures durability and heat resistance.
It has dimensions of 19.9 mm in length, 11.1 mm in width, and 18.3 mm in depth.
It is designed for an operating temperature range from -40°C to +115°C.
The wire connection is made via a screw method, ensuring secure and stable contact.
This model features 5 contact points.
The pitch for this terminal block is 3.81 mm.
It is ideal for electronic manufacturing, power distribution terminals, and industrial automation.
It complies with RoHS and lead-free standards, ensuring environmental safety.
This terminal block is designed for vertical orientation.
