Wurth Elektronik WR-TBL Series Pluggable Terminal Block 8-Contact, 3.81 mm Pitch, 1 Row 691348300008
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 1.6kV ac |
| Brand | Wurth Elektronik |
| Colour | Green |
| Orientation | Vertical |
| Current | 8A |
| Length | 31.3mm |
| Depth | 18.3mm |
| Width | 11.1mm |
| Housing Material | Polyamide 66 |
| Series | WR-TBL |
| Number of Rows | 1 |
| Pitch | 3.81mm |
| Standards/Approvals | RoHS |
| Number of Contacts | 8 |
| Minimum Wire Size mm² | 0.05mm² |
| Maximum Wire Size mm² | 2.08mm² |
| Minimum Wire Size AWG | 30AWG |
| Maximum Wire Size AWG | 14AWG |
| Wire Connection Method | Screw |
Key Features
- Constructed with polyamide 66 housing for durability.
- Supports a current rating of 8 A, suitable for moderate electrical loads.
- Accommodates wire sizes from 30 AWG to 14 AWG (0.05 mm² to 2.08 mm²).
- Compact dimensions with length of 31.3 mm, width 11.1 mm, and depth 18.3 mm.
- Green-colored housing improves visual identification and compliance with standards.
- Meets RoHS environmental compliance requirements.
- Operating temperature range of -40°C to +115°C for reliability in varied environments.
Product Description
The Wurth Elektronik 691348300008 WR-TBL Series Pluggable Terminal Block is engineered for reliable electrical connections in industrial and electronic applications. Featuring 8 contacts spaced at a 3.81 mm pitch in a single row, this vertical entry terminal block allows secure wire connections using screw terminals.
The robust polyamide 66 housing offers durability and resistance to environmental stress. Rated to carry up to 8 A current, it supports wire sizes from 30 AWG (0.05 mm²) up to 14 AWG (2.08 mm²), accommodating a broad spectrum of wiring requirements.
With a withstand voltage of 1.6 kV AC, it ensures excellent insulation and safety conformity. The green housing color aids in visual identification and meets RoHS standards, supporting sustainable manufacturing practices.
Compact dimensions of 31.3 mm length, 11.1 mm width, and 18.3 mm depth make it suitable for space-constrained applications. The terminal block operates reliably across temperatures ranging from -40°C to +115°C, suitable for use in demanding industrial, manufacturing, and electrical control environments.
This pluggable terminal block is ideal for use in PCB assemblies, control panels, and equipment requiring secure, serviceable connections. Its screw connection method guarantees firm wire retention and easy installation or maintenance.
Constructed with polyamide 66 housing for durability. Supports a current rating of 8 A, suitable for moderate electrical loads. Accommodates wire sizes from 30 AWG to 14 AWG (0.05 mm² to 2.08 mm²). Voltage rating of 1.6 kV AC ensures high insulation performance.
Compact dimensions with length of 31.3 mm, width 11.1 mm, and depth 18.3 mm. Green-colored housing improves visual identification and compliance with standards. Meets RoHS environmental compliance requirements. Operating temperature range of -40°C to +115°C for reliability in varied environments.
Explore more Wurth Elektronik components and connectors at EnvMart for innovative solutions in electronics manufacturing and industrial automation.
Explore more products in our Pluggable Terminal Blocks category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
It supports a current rating of 8 A, making it suitable for moderate electrical loads.
The voltage rating is 1.6 kV AC, ensuring high insulation performance.
It accommodates wire sizes from 30 AWG (0.05 mm²) to 14 AWG (2.08 mm²).
The compact dimensions are 31.3 mm in length, 11.1 mm in width, and 18.3 mm in depth.
The housing is constructed from polyamide 66, providing durability and resistance to environmental stress.
The contacts are spaced at a pitch of 3.81 mm in a single row.
It operates reliably across a temperature range of -40°C to +115°C.
This model features 8 contacts.
The wire connection method is screw-based, ensuring firm wire retention.
Yes, it meets RoHS environmental compliance requirements.
It is ideal for use in PCB assemblies, control panels, and equipment requiring secure, serviceable connections.
The housing is green, which aids in visual identification and compliance with standards.
