TE Connectivity Micro MATE-N-LOK Series Straight Surface PCB Header 2 Contacts 3 mm Pitch 1 Row Shrouded 2-1445053-2

Free Delivery in India | Lowest Global Shipping Charges

TE Connectivity Micro MATE-N-LOK Series Straight Surface PCB Header 2 Contacts 3 mm Pitch 1 Row Shrouded 2-1445053-2

Name: TE Connectivity Micro MATE-N-LOK Series Straight Surface PCB Header 2 Contacts 3 mm Pitch 1 Row Shrouded 2-1445053-2
Brand: TE Connectivity
SKU: 217909
Price: 1.82 USD
Availability: InStock



Category PCB Connectors & Wire Housings Brand TE Connectivity Condition New

Specifications

Country of Origin	India
Voltage	250V
Brand	TE Connectivity
Orientation	Straight
Current	5A
Mount Type	Surface
Housing Material	Nylon
Contact Material	Brass
Series	Micro MATE-N-LOK
Termination Type	Solder
Maximum Operating Temperature	105°C
Minimum Operating Temperature	0°C
Number of Rows	1
Pitch	3mm
Contact Plating	Tin
Number of Contacts	2
Contact Gender	Male
Shrouded/Unshrouded	Shrouded
Connector System	Wire-to-Board

Key Features

The header features a straight orientation and is shrouded for protection.
It is designed for surface mounting on PCBs with a single row configuration.
Housing material is durable nylon ensuring insulation and mechanical stability.
Brass contacts plated with tin provide excellent conductivity and corrosion resistance.
The connector supports up to 5 A current and 250 V voltage rating.
Operating temperature range is 0°C to 105°C, suitable for diverse industrial environments.
Polarization and positive lock tabs prevent mis-mating and secure connection to the cable connector.
Solder termination type enables robust attachment to PCB.

Product Description

TE Connectivity 2-1445053-2 Micro MATE-N-LOK Series Straight Surface PCB Header is a reliable electronic component designed for wire-to-board connections on printed circuit boards. It features 2 male contacts spaced at a 3 mm pitch, arranged in a single row. The housing is made from high-quality nylon providing electrical insulation and mechanical durability. This shrouded header offers protection against accidental contact and ensures correct orientation.

The connector supports a current rating of 5 A and voltage up to 250 V, suitable for a variety of industrial and commercial electronic applications. It can withstand operating temperatures from 0°C to 105°C, making it appropriate for environments with moderate thermal demands.

TE Connectivity’s Micro MATE-N-LOK provides polarization features to prevent mis-mating and positive locking tabs to secure the connector to the mating cable assembly. The surface mount type and solder termination provide a strong, resistant connection on PCBs essential for reliable operation.

Typical applications include household appliances, lighting systems, factory automation equipment, data storage devices, and security systems. The low-profile design versions of this connector series are ideal for LED lighting applications, but the standard model fulfills wider industrial use cases.

The header uses brass contacts with tin plating for enhanced conductivity and corrosion resistance. Polarization and positive lock tabs ensure robust and secure connectivity. Suitable for surface mounting, enabling easy integration into various PCB designs.

Compatible with a wide range of wire-to-board connection requirements across industries. Compact 3 mm pitch allows efficient PCB space utilization. Explore the extensive range of TE Connectivity connectors on EnvMart to find the solution that best fits your industrial or commercial project needs.
