TE Connectivity Universal MATE-N-LOK Series Straight Through Hole PCB Socket 6-Contact 2 Row 6.35 mm Pitch 600V 15A 643424-1
Specifications
| Country of Origin | India |
|---|---|
| Voltage | 600V |
| Brand | TE Connectivity |
| Orientation | Straight |
| Current | 15A |
| Model | 643424-1 |
| Mount Type | Through Hole |
| Housing Material | Nylon |
| Contact Material | Bronze |
| Series | Universal MATE-N-LOK |
| Termination Type | Solder |
| Maximum Operating Temperature | 85°C |
| Sub Type | Header |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 6.35mm |
| Contact Plating | Tin |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Wire-to-Board |
Key Features
- Designed for through-hole mounting with a straight orientation.
- Constructed with durable nylon housing for insulation and toughness.
- Supports a rated current of 15 amperes and voltage up to 600 volts.
- Features bronze female contacts with tin plating to ensure corrosion resistance.
- Operates reliably in temperatures ranging from -55°C to 85°C.
- Compatible with Universal MATE-N-LOK and MATE-N-LOK II plug housings.
- Ideal for wire-to-board connector applications in electronic assemblies.
- Provides stable mechanical and electrical connection in PCB installations.
Product Description
TE Connectivity 643424-1 Universal MATE-N-LOK Series Straight Through Hole PCB Socket is a precision electrical connector designed for reliable and efficient wire-to-board connections in electronic equipment. This PCB socket has 6 female contacts arranged in 2 rows, spaced at a 6.35 mm pitch suitable for through-hole solder mounting on printed circuit boards. It supports currents up to 15A and voltages up to 600V, making it ideal for moderate power applications.
The housing is made of sturdy nylon material, providing electrical insulation and mechanical durability. The female contacts are made of bronze with tin plating that offers excellent corrosion resistance to maintain reliable conductivity over time. This socket operates across a wide temperature range from -55°C to 85°C, allowing its use in diverse industrial, manufacturing, and electronic environments.
Compatible with both Universal MATE-N-LOK and Universal MATE-N-LOK II plug housings, it facilitates seamless integration within connector systems. The connector features a straight orientation ensuring efficient PCB layout and assembly processes. No specific industry standards or certifications are indicated for this product.
This component is suitable for applications in industrial electronics, power connectors, control equipment, automation systems, and other electronic module assemblies where secure, high-current connections are necessary.
Designed for through-hole mounting with a straight orientation. Housing material is nylon for durability and insulation. Rated for 15 amperes current and 600 volts voltage. Bronze female contacts with tin plating for corrosion resistance.
Temperature rating from -55°C to 85°C suitable for varied environments. Compatible with Universal MATE-N-LOK and MATE-N-LOK II plug housings. Ideal for wire-to-board applications in electronic devices and systems. Ensures stable mechanical and electrical connections on PCBs.
No certifications or approvals specified. Explore more from TE Connectivity connectors and electronic components available at EnvMart to enable your industrial and electronics projects with high-quality products.
Explore more products in our Electronics Components category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This PCB socket supports a maximum current rating of 15 amperes.
It can handle voltages up to 600 volts.
The operating temperature range is from -55°C to 85°C.
This connector features 6 female contacts arranged in 2 rows.
The pitch size of the contacts is 6.35 mm.
The housing is made of nylon, and the female contacts are made of bronze with tin plating for corrosion resistance.
Yes, it is compatible with both Universal MATE-N-LOK and MATE-N-LOK II plug housings.
This model supports through-hole mounting.
The termination type for this socket is solder.
It is suitable for wire-to-board applications in industrial electronics, power connectors, and control equipment.
The orientation of this socket is straight, designed for efficient PCB layout.
The country of origin for this product is India.
