Preci-Dip 803 Series Right Angle Surface PCB Socket 6-Contact 2 Row 2.54 mm Pitch Solder 803-87-006-30-002101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Right Angle |
| Current | 12A |
| Mount Type | Surface |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 6 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Manufactured with black glass filled polyester housing for durability.
- Features a right angle orientation for board-to-board connection.
- Current rating of 12 A supports reliable electrical performance.
- Contacts made of beryllium copper alloy with gold flash plating for enhanced conductivity.
- Operates within temperature range from -55°C to 125°C.
- Designed with 2.54 mm pitch and 2 rows to fit standard PCB layouts.
- Socket connector system supports board-to-board applications.
- Swiss manufactured ensuring high quality standards.
Product Description
Preci-Dip 803-87-006-30-002101 is a right angle surface mount PCB socket featuring 6 female contacts arranged in 2 rows with a 2.54 mm pitch. This connector is designed for board-to-board connection systems, offering a reliable solder termination and robust performance in demanding electronic applications.
The housing is constructed of black glass filled polyester material, providing durability and stability in harsh industrial environments. Each contact is made of beryllium copper alloy with a gold flash plating, optimizing electrical conductivity and resistance against corrosion.
With a current rating of 12 A and voltage rating of 150 V, this socket ensures reliable power transmission while maintaining safety standards. The product operates effectively over a broad temperature range from -55°C to 125°C, making it suitable for various industrial, electronic manufacturing, and lab environments.
Preci-Dip sockets are designed for precision and ease of assembly, compatible with standard PCB layouts requiring 2 rows of contacts at 2.54 mm pitch. The right angle orientation supports compact circuit designs and board stacking.
Black glass filled polyester housing for mechanical strength. Gold flash plated beryllium copper alloy contacts for excellent electrical conductivity. Rated for 12 A current and 150 V voltage capacity. Operational temperature range from -55°C to 125°C.
Right angle surface mount design ensures efficient board-to-board connections. Ideal for industrial electronics, manufacturing, and laboratory PCB applications.
Manufactured in Switzerland, this PCB socket adheres to strict quality control and manufacturing standards. It is suitable for demanding electronics requiring reliable connections and durability.
Explore more products in PCB Sockets and connectors at EnvMart.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
This model has a current rating of 12 A, ensuring reliable electrical performance for various applications.
The voltage rating for this socket is 150 V, suitable for a range of electronic applications.
It features a 2.54 mm pitch and is designed with 2 rows of contacts, allowing compatibility with standard PCB layouts.
The contacts are made of beryllium copper alloy and are gold flash plated to enhance conductivity and resist corrosion.
It operates effectively within a temperature range of -55°C to 125°C, making it suitable for various environments.
This model utilizes solder termination, providing a reliable connection for board-to-board applications.
This socket features 6 female contacts, designed for efficient board-to-board connections.
It has a right angle orientation, which supports compact circuit designs and board stacking.
This product is manufactured in Switzerland, adhering to strict quality control and manufacturing standards.
This model is designed for surface mounting, making it suitable for various PCB applications.
It is designed as a board-to-board connector system, ideal for connecting multiple PCBs together.
The housing is constructed from black glass filled polyester, providing mechanical strength and stability.
