Preci-Dip 803 Series Straight PCB Socket, 18-Contact, 2 Row, 2.54 mm Pitch Solder 803-87-018-10-001101
Specifications
| Country of Origin | Switzerland |
|---|---|
| Voltage | 150V |
| Brand | Preci-Dip |
| Orientation | Straight |
| Current | 12A |
| Mount Type | PCB |
| Housing Material | Black Glass Filled Polyester |
| Contact Material | Beryllium Copper Alloy |
| Series | 803 |
| Termination Type | Solder |
| Maximum Operating Temperature | 125°C |
| Sub Type | Board-to-Board |
| Minimum Operating Temperature | -55°C |
| Number of Rows | 2 |
| Pitch | 2.54mm |
| Contact Plating | Gold Flash |
| Number of Contacts | 18 |
| Contact Gender | Female |
| Connector System | Board-to-Board |
Key Features
- Designed with a black glass filled polyester housing for durability.
- Supports a maximum current of 12A and voltage of 150V.
- Features beryllium copper alloy female contacts with gold flash plating for excellent conductivity.
- Operates reliably in temperatures from -55°C to 125°C.
- Suitable for PCB mounting with straight orientation.
- Connector system is board-to-board ensuring secure electrical connection.
- Ideal for industrial electronics and precision applications.
- Manufactured in Switzerland with high-quality standards ensuring long life.
Product Description
Preci-Dip 803-87-018-10-001101 PCB Socket is a high-quality 18-contact, 2-row, straight orientation board-to-board connector designed for precise and durable PCB connections. It features a robust black glass filled polyester housing and beryllium copper alloy female contacts with gold flash plating that ensure excellent electrical conductivity and resistance to corrosion.
This solder termination socket supports currents up to 12A and voltages up to 150V, making it suitable for a variety of industrial electronics, manufacturing, and laboratory applications. It operates reliably within a wide temperature range from -55°C to 125°C, enabling use in demanding environments.
Manufactured in Switzerland, the 803 series sockets comply with UL 94V-0 flame retardant standard, ensuring safety and quality. The 2.54 mm pitch and 2-row configuration allow for compact and secure board-to-board connections, ideal for precision electronic assemblies.
The product's design includes gold flash plated beryllium copper alloy contact clips which provide reliable, low-resistance connection. This socket facilitates high-efficiency manufacturing due to its through-hole PCB mounting and straight orientation, suitable for automated insertion processes.
Black glass filled polyester housing for enhanced durability. 18 female contacts with gold flash plating for superior conductivity. Supports 12A current and 150V voltage rating. Wide operating temperature range from -55°C to 125°C.
Board-to-board connector system with 2.54 mm pitch and 2 rows. Manufactured in Switzerland ensuring quality and reliability. Complies with UL 94V-0 standards for flame retardancy. Solder termination suitable for reliable PCB mounting.
This Preci-Dip PCB socket is extensively used in electronics manufacturing, industrial equipment, laboratory instruments, and precision electronic devices where reliable and secure PCB connections are critical. Explore the Electronics Components category to discover more PCB connectors and sockets at EnvMart.
Explore more products in our PCB Sockets category.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The maximum current rating for this model is 12A.
This socket supports a voltage rating of 150V.
It operates reliably within a temperature range from -55°C to 125°C.
The housing is made of black glass filled polyester, and the contacts are made of beryllium copper alloy with gold flash plating.
This model features 18 female contacts.
The pitch of the contacts is 2.54 mm.
It uses solder termination for PCB mounting.
The orientation of this socket is straight.
It utilizes a board-to-board connector system.
This socket is manufactured in Switzerland.
It complies with the UL 94V-0 flame retardant standard.
It is suitable for industrial electronics, manufacturing, and laboratory applications where reliable PCB connections are critical.
