Panasonic PCB Signal Relay 12V dc Coil 1A DPDT FTR-B4 Series AGN26012
Specifications
| Country of Origin | Japan |
|---|---|
| Brand | Panasonic |
| Height | 9mm |
| Length | 10.9mm |
| Model | AGN26012 |
| Width | 5.7mm |
| Mount Type | PCB |
| Contact Material | Gold Plated Silver Aluminium |
| Series | FTR-B4 |
| Maximum Operating Temperature | 85°C |
| Contact Configuration | DPDT |
| Minimum Operating Temperature | -40°C |
| Switching Current | 1A |
| Terminal type | PCB Terminal |
| Standards/Approvals | RoHS |
| Coil Resistance | 1440Ω |
| Coil Voltage | 12V dc |
| Switching DC Voltage | 110V dc |
| Switching AC Voltage | 125V ac |
| Coil Power | 100mW |
Key Features
- The relay features a compact slim body measuring 9mm height and 5.7 x 10.9 mm footprint.
- It offers high contact reliability with twin crossbar contacts and gold plated silver aluminium contact material.
- Coil power is low at 100mW with a coil resistance of 1440Ω, optimizing energy consumption.
- The relay supports switching voltages up to 125V ac and 110V dc.
- It is designed for PCB mounting with PCB terminals for easy integration.
- Operating temperature ranges from -40°C to 85°C for versatile environmental conditions.
- The sealed construction allows automatic washing and provides high surge resistance and vibration/shock tolerance.
- Typical use cases include telecommunications, measurement, and audio visual equipment.
Product Description
Panasonic AGN26012 PCB Signal Relay is an ultra-small, highly reliable signal relay designed for PCB mounting in industrial, telecommunications, measurement, and audio visual equipment applications. Featuring a 12V dc coil and a 1A switching current with DPDT contact configuration, this relay provides excellent performance within a compact form factor of 9mm height and 5.7 x 10.9 mm footprint.
The twin crossbar contact system ensures high contact reliability, and the gold plated silver aluminium contacts resist corrosion and wear. The relay operates efficiently at 100mW coil power and includes a coil resistance of 1440Ω. It supports switching voltages up to 125V ac and 110V dc, making it suitable for various signal switching requirements.
Built with a sealed construction, the AGN26012 is suitable for automatic washing and offers outstanding surge resistance along with high vibration and shock tolerance. It operates reliably in harsh environments with an operating temperature range from -40°C to 85°C. The PCB terminals facilitate straightforward mounting on printed circuit boards, enhancing packaging density for compact electronics.
Applications for this model include telecommunications devices, measurement and control equipment, and audio visual systems that demand precise and robust Signal Relay operation. Manufactured in Japan under the FTR-B4 series, it complies with RoHS standards and fits the industrial requirements for size, power efficiency, and environmental robustness.
The relay features a compact slim body measuring 9mm height and 5.7 x 10.9 mm footprint. It offers high contact reliability with twin crossbar contacts and gold plated silver aluminium contact material. Coil power is low at 100mW with a coil resistance of 1440Ω, optimizing energy consumption.
The relay supports switching voltages up to 125V ac and 110V dc. It is designed for PCB mounting with PCB terminals for easy integration. Operating temperature ranges from -40°C to 85°C for versatile environmental conditions.
The sealed construction allows automatic washing and provides high surge resistance and vibration/shock tolerance. Typical use cases include telecommunications, measurement, and audio visual equipment.
Looking to purchase in bulk?
- Purchase item in bulk quantity
- Get best price for your business
Frequently Asked Questions
The relay has a switching current rating of 1A.
This model has a height of 9mm, a length of 10.9mm, and a width of 5.7mm.
The coil voltage for this relay is 12V DC.
It supports a maximum switching voltage of 125V AC and 110V DC.
It is designed for PCB mounting with PCB terminals for easy integration.
The coil power consumption is low at 100mW.
This relay features a DPDT (Double Pole Double Throw) contact configuration.
The operating temperature range is from -40°C to 85°C.
The contacts are made of gold plated silver aluminium, which enhances reliability.
This model complies with RoHS standards.
It is suitable for telecommunications, measurement, and audio visual equipment applications.
The sealed construction allows for automatic washing and provides high surge resistance and vibration/shock tolerance.
