Schurter Non-Resettable Fuse 2.5A 125V DC 250V AC Ceramic Body Time Delay 3404.2420.22

Free Delivery in India | Lowest Global Shipping Charges

Schurter Non-Resettable Fuse 2.5A 125V DC 250V AC Ceramic Body Time Delay 3404.2420.22

Name: Schurter Non-Resettable Fuse 2.5A 125V DC 250V AC Ceramic Body Time Delay 3404.2420.22
Brand: Schurter
SKU: 425487
Price: 1.37 USD
Availability: InStock



Category Non Resettable Fuse Brand Schurter Condition New

Specifications

Country of Origin	Switzerland
Voltage	125, 250V dc
Brand	Schurter
Body Material	Ceramic
Height	3.9mm
Depth	10.1mm
Width	3.8mm
Current Rating	2.5A
Series	UMZ 250
Maximum Operating Temperature	-40°C
Package Type	Reel
Minimum Operating Temperature	85°C
Breaking Capacity	200A
Terminal Material	Gold Plated Copper
Standards/Approvals	RoHS, REACH, UL 248-14, CE, CSA
Fuse Characteristics	Time Delay
Schurter Surface Mount Fuse 2.5ABrand	Schurter

Key Features

The fuse offers high breaking capacity of 200A for robust circuit protection.
Its compact dimensions of 3.8mm width, 3.9mm height, and 10.1mm depth enable space-saving installation.
Gold plated copper terminals enhance conductivity and corrosion resistance.
Supports a wide operating temperature range from -40°C to 85°C.
Adheres to international standards including RoHS, REACH, UL 248-14, CE, and CSA.
Ideal for protecting high-value silicon ICs in devices such as alarm systems, power supplies, and medical apparatus.
Designed for surface mount technology, facilitating efficient automated assembly.

Product Description

Schurter 3404.2420.22 is a Non-Resettable Fuse with a current rating of 2.5A designed for both AC and DC voltage applications of 250V AC and 125V DC. The ceramic body construction provides reliable thermal and electrical insulation, ensuring durability in demanding electrical environments.

This fuse features a time delay (time-lag) characteristic, allowing for temporary surges without nuisance blowing, making it ideal for sensitive electronics protection. It has a high breaking capacity of 200A, enabling it to safely interrupt fault currents and protect circuits from damage.

The compact size with dimensions of 3.8mm in width, 3.9mm in height, and 10.1mm in depth supports surface mount technology, facilitating automated and space-saving PCB assembly. Gold plated copper terminals ensure excellent electrical contact and resistance to corrosion.

Operating temperature tolerance ranges from -40°C to 85°C, allowing use in a wide variety of industrial and commercial conditions.

Schurter 3404.2420.22 fuses comply with international safety and environmental standards such as RoHS, REACH, UL 248-14, CE, and CSA, confirming its suitability for global markets and diverse applications.

This fuse is extensively used in applications requiring secure protection of high-value integrated circuits, including alarm systems, computer motherboards, portable telephones, audio/video equipment, power supplies, and medical devices.

The fuse offers high breaking capacity of 200A for robust circuit protection. Its compact dimensions of 3.8mm width, 3.9mm height, and 10.1mm depth enable space-saving installation. Gold plated copper terminals enhance conductivity and corrosion resistance.

Supports a wide operating temperature range from -40°C to 85°C. Adheres to international standards including RoHS, REACH, UL 248-14, CE, and CSA. Ideal for protecting high-value silicon ICs in devices such as alarm systems, power supplies, and medical apparatus.

Designed for surface mount technology, facilitating efficient automated assembly. Explore similar high-quality non-resettable fuses and other circuit protection solutions in the Electronics & Electricals category at EnvMart.
